07 EffLab_V5.07 NL

;;-----------------------------------------------------------------------------|
;; SECTION A – AUTHOR IDENTIFICATION AND CODE ABSTRACT
;;-----------------------------------------------------------------------------|
;;
;; File Name: EffLab_I_V5.06.nlogo
;; By Orrery Software
;; Dated: 2019-10-06
;; Author contact:
;;   Garvin H Boyle
;;   orrery@rogers.com
;;   http://orrery-software.webs.com

;; As the author, I welcome questions, discussion of issues and suggestions
;;   for improvements.

;;-----------------------------------------------------------------------------|
;; This EffLab app is a laboratory in which students can study aspects
;;   of the phenomenon of efficiency as described in my
;;   associated diary notes.

;; In this model, nrg arrives in a steady stream from the Sun and is captured
;;   in plants that produce fruit, which appears randomly in dales in the
;;   forest.  Nomadic seekers roaming the forest according to their own
;;   heuristic strategy seek the dales currently having food, and harvest it.
;;   The strategies start as ineffective bland heuristics, and evolve to be
;;   much more sophisticated. In the most simple scenario, all actions are
;;   instinctive.  The efficiency is calculated for individual seekers, as well
;;   as for the trophic level (seekers) as a whole.

;;-----------------------------------------------------------------------------|
;; SECTION B – INITIAL DECLARATIONS OF GLOBALS AND BREEDS
;;-----------------------------------------------------------------------------|
;;
;;-----------------------------------------------------------------------------|
;; This program was developed on NetLogo Version 5.0.5
;;

;;-----------------------------------------------------------------------------|
;; code-determined global variables
globals
[
  ;; The version should be coded in this global variable to be included in
  ;;   output files.
  gs-Version

  ;; Note: Some global variables are declared inside of switches, sliders and
  ;;   choosers when the interface is constructed and are not declared here.
  ;;   For the sake of clarity and completeness, they are noted here.

  ;; There are several uses of global variables:
  ;;  - Toggles (switches), and choosers which enable or disable features;
  ;;  - Numbers (in variables or sliders) which act as parameters;
  ;;  - Numbers (in variables) which collect data.
  ;;
  ;; Those marked as 'native Boolean' have values of true or false.
  ;; Those marked as 'numeric Boolean' have values of 1 or 0.

  ;;---------------------
  ;; MODELING ENVIRONMENT
  ;;---------------------

  ;; Assumed “Model Settings” on startup
  ;; horizontal wrap: on
  ;; vertical wrap: on
  ;; location of origin: centre
  ;; patch size: 10 pixels
  ;;-------------------------------------------------------------------------|
  ;; Implicit global variables due to model settings – patch locations
  ;; min-pxcor  -45
  ;; max-pxcor   45
  ;; min-pycor  -20
  ;; max-pycor   20
  ;; So, the arena is 41 x 91 cells.

  ;;----------------------------
  ;; SCENARIO SELECTION CONTROLS
  ;;----------------------------

  ;; gs-scenario         ;; Chooser, string converts to a scenario number
  g-scenario-number      ;; scenario no.; 0; interp. of gs-scenario
  ;; Glogal enumeration variables - There is only 1 scenario possible.
  ge-scenario-zero       ;; scenario 0, Small Beginnings
  ge-scenario-one        ;; scenario 1, At Carrying Capacity
  ;; g-seekers-at-start  ;; For Scenario 0, [1,1,100,10]

  ;; To halt a scenario at a pre-determined tick.
  ;; g-halt-at-tick      ;; Has it's own input box

  ;; Initialize the Pseudo Random Number Generator (PRNG).
  ;; g-use-this-seed     ;; Slider [1,1,100,7]

  ;;-----------------------------------------------
  ;; BIOPHYSICAL SUB-SYSTEM CONTROLS AND PARAMETERS
  ;;-----------------------------------------------

  ;; Biophyscial life function parameters, seekers.
  ;; g-c2-dat-parm  ;; The death age threshold
  ;; g-c2-det-parm  ;; The death nrg threshold
  ;; g-c2-rat-parm  ;; The reproductive age threshold
  ;; g-c2-ret-parm  ;; The reproductive nrg threshold
  ;; g-c2-epm-parm  ;; The nrg per move
  ;; g-c2-epa-parm  ;; The maximum nrg an agent may hold

  ;; The global list of possible heading deltas for moves.
  gl-heading-list  ;; List of heading deltas.
  gl-index-list    ;; List of numbers 0-7 in order
  gl-base-factors  ;; List of factors, used to mutate bases

  ;; Nrg control variables
  ;; g-nrg-per-deposit  ;; Nrg deposited per Dale [1,1,100,40]
  ;; g-prob-of-deposit  ;; Prob nrg will be deposited [0,.001,1,.05]
  ;; g-heuristic-delta  ;; Amount added to heuristic on success [0,.001,2,1]
  ;; g-prob-of-mutation ;; As it says [0,.001,1,0.95]
  ;; g-dt-for-ind-stats      ;; Delta time, used for EROI [40,40,400,200]

  ;; Nrg accounting variables
  g-nrg-in-fruit        ;; Nrg held in the fruit.
  g-nrg-in-agents       ;; Nrg held in the agents.
  g-nrg-in-system       ;; Total nrg in the system.
  g-sun-takeup-actual   ;; As measured

  ;; Global enumeration (ge-) codes for cause of death.
  ge-cod-none
  ge-cod-fission
  ge-cod-hunger
  ge-cod-oldage

  ;; List to hold counts of cause of death.
  gl-causes-of-death-per-tick
  gl-causes-of-death-cumulative

  ;;-------------------------------------
  ;; END OF MODEL PARAMETERS AND CONTROLS
  ;;-------------------------------------

  ;;-------------------------------------
  ;; DATA COLLECTION AND DISPLAY CONTROLS
  ;;-------------------------------------

  ;; The following global variables are not model controls or paramaters,
  ;;   but, rather, are variables used to collect data about the model
  ;;   for display in the user interface, in some fashion (monitors or plots),
  ;;   or used to manage all of the debug routines and output.

  ;; Global enumeration (ge-) codes.
  ge-sinktype-discard   ;; Discarded sunlight
  ge-sinktype-move-EPM  ;; Seekers EPM
  ge-sinktype-die-DET   ;; Remaining nrg of seeker on death.
  ge-sinktype-die-DAT   ;; Remaining nrg of seeker on death.
  ge-sinktype-repro-RET ;; Nrg passed mother to daughter, NOT A HEAT SINK.

  ;; SYSTEM-WIDE AGGREGATES
  ;; System of nrg sinks.
  gl-sinks-per-tick
  gl-sinks-cumulative

  ;;---------------------------------------------------------------------------|
  ;; The following agent sets, counts and averages are for data collection
  ;;   and display in monitors and plots.

  ;; Global counts
  g-no-of-patches          ;; count of all patches
  g-no-of-dales            ;; count of all dales with fruit
  g-no-of-empty-patches    ;; count of all empty patches
  g-no-of-seekers          ;; count of all seekers
  g-carrying-capacity      ;; sustainable load of seekers

  ;; Global EROI/ETA system-wide calculations.
  g-sys-nrg-returned      ;; Gross nrg returned (er) within delta T.
  g-sys-nrg-invested      ;; Gross nrg invested (ei) within delta T.
  g-sys-nrg-benefits      ;; Net nrg returned or benefits (er-ei) within delta T.
  gl-sys-nrg-returned     ;; List of changes.
  gl-sys-nrg-invested     ;; List of changes.
  g-sys-eroi              ;; System-wide EROI, per tick =(I/C).
  g-sys-eta               ;; System-wide ETA, per tick  =(B/I).

  ;; Global lists for EROI/ETA for death by repro/hunger.
  g-dbr-stat-count        ;; Count of agents included in lists
  g-dbh-stat-count        ;; Count of agents included in lists
  g-dbo-stat-count        ;; Count of agents included in lists
  ;; g-max-for-lte-stats  ;; Maximum agents included [40,40,5000,5000]
  gl-lte-eroi-dbr         ;; List of EROI for death by repro
  gl-lte-eroi-dbh         ;; List of EROI for death by hunger
  gl-lte-eroi-dbo         ;; List of EROI for death by old age
  gl-lte-eroi-all         ;; List of EROI for death by all causes
  gl-lte-eta-dbr          ;; List of ETA for death by repro
  gl-lte-eta-dbh          ;; List of ETA for death by hunger
  gl-lte-eta-dbo          ;; List of ETA for death by old age
  gl-lte-eta-all          ;; List of ETA for death by all causes
  g-lte-eta-min           ;; Used to set min value for histograms
  g-lte-eroi-max          ;; Used to set max value for histograms

  ;; Other histogram limits
  g-hist-epm-max          ;; Max value for EPM histogram
  g-hist-epm-min          ;; Min value for EPM histogram
  g-hist-epa-max          ;; Max value for EPA histogram
  g-hist-epa-min          ;; Min value for EPA histogram

  ;; Averages for seekers
  g-ave-age               ;; age of seekers
  g-ave-nrg               ;; nrg of seekers
  g-ind-min-eroi          ;; min eroi of individual seekers = (B/C)
  g-ind-ave-eroi          ;; ave eroi of individual seekers = (B/C)
  g-ind-max-eroi          ;; max eroi of individual seekers = (B/C)
  g-ind-min-eta           ;; min eta of individual seekers  = (B/I)
  g-ind-ave-eta           ;; ave eta of individual seekers  = (B/I)
  g-ind-max-eta           ;; max eta of individual seekers  = (B/I)

  g-ave-C1-b0             ;; c1, base character, gene-0
  g-ave-C1-b1             ;; c1, base character, gene-1
  g-ave-C1-b2             ;; c1, base character, gene-2
  g-ave-C1-b3             ;; c1, base character, gene-3
  g-ave-C1-b4             ;; c1, base character, gene-4
  g-ave-C1-b5             ;; c1, base character, gene-5
  g-ave-C1-b6             ;; c1, base character, gene-6
  g-ave-C1-b7             ;; c1, base character, gene-7

  g-ave-c1-e0             ;; c1, exponent character, gene-0
  g-ave-c1-e1             ;; c1, exponent character, gene-1
  g-ave-c1-e2             ;; c1, exponent character, gene-2
  g-ave-c1-e3             ;; c1, exponent character, gene-3
  g-ave-c1-e4             ;; c1, exponent character, gene-4
  g-ave-c1-e5             ;; c1, exponent character, gene-5
  g-ave-c1-e6             ;; c1, exponent character, gene-6
  g-ave-c1-e7             ;; c1, exponent character, gene-7

  g-ave-C1-s0             ;; c1, strength character, gene-0
  g-ave-C1-s1             ;; c1, strength character, gene-1
  g-ave-C1-s2             ;; c1, strength character, gene-2
  g-ave-C1-s3             ;; c1, strength character, gene-3
  g-ave-C1-s4             ;; c1, strength character, gene-4
  g-ave-C1-s5             ;; c1, strength character, gene-5
  g-ave-C1-s6             ;; c1, strength character, gene-6
  g-ave-C1-s7             ;; c1, strength character, gene-7

  g-ave-C1-p0             ;; c1, phenotypic character, gene-0
  g-ave-C1-p1             ;; c1, phenotypic character, gene-1
  g-ave-C1-p2             ;; c1, phenotypic character, gene-2
  g-ave-C1-p3             ;; c1, phenotypic character, gene-3
  g-ave-C1-p4             ;; c1, phenotypic character, gene-4
  g-ave-C1-p5             ;; c1, phenotypic character, gene-5
  g-ave-C1-p6             ;; c1, phenotypic character, gene-6
  g-ave-C1-p7             ;; c1, phenotypic character, gene-7

  ;; Variables used to calculate and display entropy.
  g-energy-entropic-index  ;; Entropy associated with energy distribution.
  g-pheno-entropic-index   ;; Entropy associated with genetic distribution.
  gl-ave-pheno             ;; Average phenotype.

  ;; SWITCHES - These are declared in the switch itself, and so are
  ;;   commented out here.  They are all native Booleans, having values of
  ;;   true or false.
  ;; gb-plot-data              ;; Enables plotting

  ;; Expanding the scope of evolutionary pressures.
  ;; gb-mutate-epm             ;; Enables mutation of EPM.
  ;; gb-mutate-epa             ;; Enables mutation of EPA.

  ;; gb-include-dnd            ;; Enables inclusion of D&D nrg uses.
  ;; D&D stands for Detrivores and Decomposers.  When agents die with
  ;;   still-useful-energy they release that energy to a sink.  This
  ;;   switch enables inclusion of that released energy in the calculation
  ;;   of EROI and ETA.

  ;; Other - built-in or declared implicitly in plot interface items
  ;; See each plot design dialogue.

  ;;---------------
  ;; DEBUG CONTROLS
  ;;---------------

  gb-debug-on                 ;; Numeric Boolean, opens debug log file, 0 or 1.
  gs-debug-status             ;; for monitor, '1 (On)' or '0 (Off)',
  ;; gs-debug-step-chooser    ;; Chooser, used with gb-debug-flow-on
  gb-debug-flow-on            ;; Numeric Boolean, in association with chooser,
  gs-log-file-name            ;; name of the debug log file
                              ;;   opens flow to log file
]

  ;;-------------------------------------
  ;; DEFINING PATCHES AND BREEDS
  ;;-------------------------------------

;;-----------------------------------------------------------------------------|
;; Attributes of patches
patches-own
[
  ;; BUILT-IN ATTRIBUTES
  ;; pxcor        ;; min-pxcor <= pxcor < max-pxcor
  ;; pycor        ;; min-pxcor <= pxcor < max-pxcor
  ;; pcolor       ;; color of this patch ( 0 <= color < 140 )
  ;; plabel       ;; label of this patch
  ;; plabel-color ;; color of this patch's label ( 0 <= label-color < 140 )

  ;; EffLab-DETERMINED ATTRIBUTES
  fruit
]

;;-----------------------------------------------------------------------------|
;; Attributes of links
;; nil
;; I don't understand links and did not use any.

;;-----------------------------------------------------------------------------|
;; Turtles and breeds
breed [ seekers seeker ]

;;-----------------------------------------------------------------------------|
;; Attributes of seekers
seekers-own
[
  ;; BUILT-IN ATTRIBUTES
  ;; who         ;; fixed id number
  ;; breed       ;; to which breed this turtle belongs [seeker]
  ;; heading     ;; 0 <= heading < 360, 0 = north
  ;; xcor        ;; min-pxcor <= xcor < max-pxcor
  ;; ycor        ;; min-pxcor <= xcor < max-pxcor
  ;; size        ;; size relative to a patch, default is 1
  ;; shape       ;; a shape chosen from the shape library
  ;; color       ;; color of this turtle ( 0 <= color < 140 )
  ;; pen-mode    ;; "up" or "down"
  ;; pen-size    ;; in pixels
  ;; hidden?     ;; true or false
  ;; label       ;; label of this turtle
  ;; label-color ;; color of this turtle's label ( 0 <= label-color < 140 )

  ;; USER-DETERMINED ATTRIBUTES
  ;; The chromosome 1 (c1) genes are used to distinguish behaviours.
  c1-bases    ;; c1 - list of 8 [B]ases for genes (S=B^E)
  c1-expos    ;; c1 - list of 8 heading delta [E]xponents
  c1-stren    ;; c1 - list of 8 [S]trengths
  c1-pheno    ;; c1 - list of 8 [P]henotypic characters (Pi=Si/sum(Sj))

  ;; The chromosome 2 (C2) genes are static in this model.
  DAT         ;; Death Age Threshold.
  DET         ;; Death Energy Threshold.
  RAT         ;; Reproductive Age Threshold.
  RET         ;; Reproductive Energy Threshold.
  EPM         ;; Energy Per Move.
  EPA         ;; Maximum Energy Per Agent.

  ;; Other variable characteristics.
  mas-who              ;; serial number of parent agent.
  age                  ;; age of the agent in ticks
  nrg                  ;; nrg in this agent
  cause-of-death       ;; for statistical purposes
  b-is-ready-to-move      ;; 0 = no; 1 = ready to move
  b-is-ready-to-reproduce ;; mature (in age) and healthy (in nrg)
  b-is-ready-to-die       ;; old (in age) or starved (in nrg)

  ;; Variables for calculating individual EROI and ETA.
  ind-nrg-returned      ;; Numerator of EROI - an aggregate = Income of (I/C)
  ind-nrg-invested      ;; Denominator of EROI - an aggregate = Costs of (I/C)
  ind-nrg-benefits      ;; Numerator of ETA - an aggregate = Benefits of (B/I)
  ind-eroi              ;; Gross nrg returned on nrg invested = (I/C)
  ind-eta               ;; Net nrg efficiency = (B/I)
  l-ind-er              ;; A list of delta ERs of length delta T
  l-ind-ei              ;; A list of delta EIs of length delta T
  ind-eroi-tick-counter ;; For tracking time up to delta T.

  ;; Life-time efficiency (lte) variables.
  lte-er               ;; Energy returned (harvested) per lifetime
  lte-ei               ;; Energy invested (spent) per lifetime
  lte-eta              ;; Life-time efficiency - eta
  lte-eroi             ;; Life-time efficiency - eroi
]

;;-----------------------------------------------------------------------------|
;; SECTION C – INITIALIZATION OR SETUP PROCEDURE( S )
;;-----------------------------------------------------------------------------|

;;-----------------------------------------------------------------------------|
;; The 'autostart' startup routine

to startup
  ;; This routine is to be executed by the observer.

  ;; The manual describes this routine as follows:
  ;; This procedure, if it exists, will be called when a model is first loaded
  ;;   in the NetLogo application.  Startup does not run when a model is run
  ;;   headless from the command line, or by parallel BehaviorSpace.

  ;; On loading the model, the debug feature is always off.
  set gb-debug-on 0
  set gs-debug-status "0 (Off)"

  ;; On loading the model, the model, the choosers, switches and sliders are
  ;;   always reset to the values that are known to work by here invoking
  ;;   the f-reset-default-parameters routine.  Only the chooser
  ;;   for the scenario is not reset.  The last saved
  ;;   selection of scenario will therefore be persistant.  This allows the
  ;;  'Reset Defaults' button to NOT reset the scenario number, but to reset
  ;;  correct parameters for the scenario.
  f-reset-default-parameters

  ;; Run the setup routine to initialize other globals.
  setup
end

;;-----------------------------------------------------------------------------|
;; Reset the default values for the interface-declared items.

to f-reset-default-parameters
  ;; The observer executes this routine.

  ;; Switches, sliders and choosers implicitly declare global variables.  The
  ;;   values in these variables are parameters for the model, and many
  ;;   combinations of those parameters are not sustainable.  However, the
  ;;   values in those user interface devices are stored with the model and
  ;;   are persistant across a save/load action.  The default values must
  ;;   be reset on load, or available to a user as a parameter set.  The
  ;;   purpose of this routine is to store at least one viable set of
  ;;   parameter values.

  ;; DO NOT re-initialize the gs-scenario chooser.  The selected scenario
  ;;   is intended to be persistent, and not subject to a default setting.

  ;; Initialize the Pseudo Random Number Generator (PRNG).
  set g-use-this-seed 7          ;; [1,1,100,7]

  set gb-plot-data true          ;; Turn plotting on.

  ;;-----------------------------------------------
  ;; BIOPHYSICAL SUB-SYSTEM CONTROLS AND PARAMETERS
  ;;-----------------------------------------------

  ;; Slider range settings are shown as (Min,Inc,Max,Default)
  set g-seekers-at-start      10 ;; For Scenario 0, [1,1,100,10]
  set g-nrg-per-deposit       40 ;; [1,1,100,40]
  set g-prob-of-deposit     0.05 ;; [0,.001,1,.05]
  set g-prob-of-mutation    0.95 ;; [0,.001,1,0.95]
  set g-max-for-lte-stats   5000 ;; [40,40,5000,5000]
  set g-dt-for-ind-stats     200 ;; [40,40,400,200]
  set gb-include-dnd       false ;; Detrivores and Decomposers not included.

  ;; Static chromosome 2 (C2) biophysical controls - borrowed from PSoup model.
  set g-c2-dat-parm        1600  ;; [100,10,3200,1600]
  set g-c2-det-parm           4  ;; [4,4,40,4]
  set g-c2-rat-parm         800  ;; [50,10,3200,800]
  set g-c2-ret-parm        1000  ;; [200,1,1600,1000]
  set g-c2-epm-parm           4  ;; [1,1,40,4]
  set g-c2-epa-parm        1600  ;; [1600,100,3000,1600]

  ;; Expanding the scope of evolutionary pressures.
  set gb-mutate-epm         true ;; Enables mutation of EPM.
  set gb-mutate-epa         true ;; Enables mutation of EPA.

  set gb-include-dnd       false ;; Enables inclusion of D&D nrg uses.

  ;; End of f-reset-default-parameters
end

;;-----------------------------------------------------------------------------|
;; The setup button(s)

to setup
  ;; This routine is to be executed by the observer.

  ;; NOTE: The contents of switches, sliders, and choosers seem to be
  ;;   immune to these 'clear' commands.
  clear-ticks
  clear-turtles
  clear-patches
  clear-drawing
  clear-all-plots
  clear-output
  ;; clear-globals   ;; Suppressed to make gb-debug-on value persistent.
  ;; NOTE: Instead of 'clear-globals', you must ensure all globals are
  ;;   initialized properly in 'setup'.

  ;; import-drawing "01-B OrrSW.jpg"

  ;; Set the nrg (encoded in the variable fruit) in all of the patches to zero.
  ask patches
  [
    set fruit 0
    set pcolor brown
  ]

  ;; The version should be coded in this global variable to be included in
  ;;   output files.
  set gs-Version "EffLab_I_V1.04"

  ;; Debug features may be off or on depending on history.
  ;;   - Perhaps 'setup' was called by 'to startup'.
  ;;   - Perhaps 'setup' was called during a 'BehaviorSpace' run.
  ;;   - Perhaps 'setup' was called by a user-pushed 'setup' button.
  ;; Setup needs to handle some quasi-persistant values correctly regardless of
  ;;   the history.  For gb-debug-on, in particular, I want it to be
  ;;   persistant so I can have debug output from the 'setup' routine routed
  ;;   to the debug log file, or to the command centre.

  ;; 'startup' automatically sets gb-debug-on to 0 when the application is first
  ;;   loaded.  I want to be able to (A) toggle debug on, then, (B) press
  ;;   'setup' and watch the debug output of the 'setup' command.  The
  ;;   gb-debug-on must be persistant through the above 'clear' commands.  The
  ;;   debug log file name and status, however, should not be persistent and
  ;;   must be reset when setup runs, if appropriate.
  ifelse ( gb-debug-on = 1 )
  [
    ;; Debug is on due to user setting, so file name and status should be
    ;;   reset.  I do this by turning the feature off then on.
    ;; First toggle it off, closing any remnant log file, if needed.
    f-toggle-debug
    ;; Then toggle it back on, opening a new time-stamped log file.
    f-toggle-debug
  ]
  ;; else
  [
    ;; Debug is off, possibly due to startup execution, possibly due to user
    ;;   choice.
    ;; Ensure associated variables have compatible settings.
    set gb-debug-on 0              ;; Redundant but ensures consistency.
    set gs-debug-status "0 (Off)"  ;; Redundant but ensures consistency.
    set gb-debug-flow-on 0         ;; Step-specific flow is off.
    file-close-all                 ;; Close the debug log file.
    set gs-log-file-name "dummyname"
  ]

  ;; Now, do the standard check that is done at the start of each debuggable
  ;;   routine.  This must follow the clear commands, which reset everything
  ;;   except globals, switches, sliders and choosers.
  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "setup" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-setup: Debug on; tick = " 0 ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; g-use-this-seed comes from a slider, and is persistant during setup.
  ;; However it is NOT persistent in a 'reset-defaults' call.
  random-seed g-use-this-seed      ;; Tells the PRNG to use this seed.

  ;; Establish the list of allowed headings, each 45 degrees from the last.
  ;;   These are the possible deltas that will be added to the current heading
  ;;   based on which of the 8 genes is expressed during a move.
  set gl-heading-list [ 0 45 90 135 180 225 270 315 ]
  set gl-index-list   [ 0 1 2 3 4 5 6 7 ]

  ;; The factors used to mutate the base values of the genes need to be
  ;;   calculated.
  let prime-list [ 7 11 13 17 ]
  let factor-list ( map [ 1 + ( 1 / ? ) ] prime-list )
  let inverse-list ( map [ 1 - ( 1 / ? ) ] prime-list )
  set gl-base-factors ( sentence factor-list inverse-list )

  ;; Glogal enumeration variables - There are 2 scenarios possible.
  set ge-scenario-zero 0  ;; Small beginnings
  set ge-scenario-one  1  ;; At Carrying Capacity
  ;; Use the input from the chooser gs-scenario to invoke the selected scenario.
  f-set-scenario-number

  ;; For debugging the setup procedure, log the values of the globals.
  LOG-TO-FILE ( word "  Do-set: Scenario number    - " g-scenario-number )
  LOG-TO-FILE ( word "  Do-set: Scenario name      - " gs-scenario )
  LOG-TO-FILE ( word "  Do-set: Random seed        - " g-use-this-seed )

  ;; Declare values of hidden declarations from sliders.
  LOG-TO-FILE ( word "  Do-set: g-nrg-per-deposit  - " g-nrg-per-deposit )
  LOG-TO-FILE ( word "  Do-set: g-prob-of-deposit  - " g-prob-of-deposit )
  LOG-TO-FILE ( word "  Do-set: g-prob-of-mutation - " g-prob-of-mutation )
  LOG-TO-FILE ( word "  Do-set: g-max-for-lte-stats - " g-max-for-lte-stats )
  LOG-TO-FILE ( word "  Do-set: g-dt-for-ind-stats - " g-dt-for-ind-stats )

  ;; Nrg accounting variables
  set g-nrg-in-agents       0 ;; Nrg held in the agents.
  set g-nrg-in-fruit        0 ;; Nrg held in the fruit.
  set g-nrg-in-system       0 ;; Nrg in the system.
  set g-sun-takeup-actual   0 ;; As measured

  ;; Global enumeration (ge-) codes for cause of death.
  set ge-cod-none     0
  set ge-cod-fission  1
  set ge-cod-hunger   2
  set ge-cod-oldage   3

  ;; List to hold counts of cause of death.
  set gl-causes-of-death-per-tick   ( n-values 4 [0] )
  set gl-causes-of-death-cumulative ( n-values 4 [0] )

  ;; Global enumeration (ge-) codes for sinktype.
  set ge-sinktype-discard     0 ;; Discarded sunlight
  set ge-sinktype-move-EPM    1 ;; Seeker EPM
  set ge-sinktype-die-DET     2 ;; Remaining nrg of seeker on death.
  set ge-sinktype-die-DAT     3 ;; Remaining nrg of seeker on death.
  set ge-sinktype-repro-RET   4 ;; Nrg passed mother to daughter, NOT A HEAT SINK.

  ;; System of nrg sinks.
  set gl-sinks-per-tick   ( n-values 5 [0] )
  set gl-sinks-cumulative ( n-values 5 [0] )

  ;; Global EROI system-wide calculations.
  set g-sys-nrg-returned      0 ;; Gross nrg returned within delta T (er).
  set g-sys-nrg-invested      0 ;; Gross nrg invested within delta T (ei).
  set g-sys-nrg-benefits      0 ;; Net nrg returned within delta T (er-ei).
  set gl-sys-nrg-returned    [] ;; List of changes.
  set gl-sys-nrg-invested    [] ;; List of changes.
  set g-sys-eroi              0 ;; System-wide EROI, per tick = (I/C).
  set g-sys-eta              -5 ;; System-wide ETA, per tick  = (B/I).

  ;; Global lists for EROI/ETA for death by xxx.
  set g-dbr-stat-count        0 ;; Count of ticks included in lists.
  set g-dbh-stat-count        0 ;; Count of ticks included in lists.
  set g-dbo-stat-count        0 ;; Count of ticks included in lists.
  ;; set g-max-for-lte-stats  0 ;; Maximum agents included [40,40,1000,1000]
  set gl-lte-eroi-dbr        [] ;; List of EROI for death by repro
  set gl-lte-eroi-dbh        [] ;; List of EROI for death by hunger
  set gl-lte-eroi-dbo        [] ;; List of EROI for death by old age
  set gl-lte-eroi-all        [] ;; List of EROI for death by all causes
  set gl-lte-eta-dbr         [] ;; List of ETA for death by repro
  set gl-lte-eta-dbh         [] ;; List of ETA for death by hunger
  set gl-lte-eta-dbo         [] ;; List of ETA for death by old age
  set gl-lte-eta-all         [] ;; List of ETA for death by all causes
  set g-lte-eta-min          -1 ;; Used to set min value for histograms
  set g-lte-eroi-max          1 ;; Used to set max value for histograms

  ;; Other histogram limits
  set g-hist-epm-max g-c2-epm-parm + 0.1 ;; Max value for EPM histogram
  set g-hist-epm-min g-c2-epm-parm - 0.1 ;; Min value for EPM histogram
  set g-hist-epa-max g-c2-epa-parm + 1   ;; Max value for EPA histogram
  set g-hist-epa-min g-c2-epa-parm - 1   ;; Min value for EPA histogram

  ;;---------------------------------------------------------------------------|
  ;; The following agent sets, counts and averages are for data collection
  ;;   and display in monitors and plots.

  ;; Counts
  set g-no-of-patches          0 ;; count of all patches
  set g-no-of-dales            0 ;; count of all dales with fruit
  set g-no-of-empty-patches    0 ;; count of all empty patches
  set g-no-of-seekers          0 ;; counts of all seekers
  set g-carrying-capacity      0 ;; sustainable load of seekers

  ;; Averages for seekers
  set g-ave-age      0        ;; age of seekers
  set g-ave-nrg      0        ;; nrg of seekers
  set g-ind-min-eroi 0        ;; min individual eroi of seekers = (I/C)
  set g-ind-ave-eroi 0        ;; ave individual eroi of seekers = (I/C)
  set g-ind-max-eroi 0        ;; max individual eroi of seekers = (I/C)
  set g-ind-min-eta  -5       ;; min individual eta of seekers = (B/I)
  set g-ind-ave-eta  -5       ;; ave individual eta of seekers = (B/I)
  set g-ind-max-eta  -5       ;; max individual eta of seekers = (B/I)

  set g-ave-C1-b0   0         ;; c1, base character, gene-0
  set g-ave-C1-b1   0         ;; c1, base character, gene-1
  set g-ave-C1-b2   0         ;; c1, base character, gene-2
  set g-ave-C1-b3   0         ;; c1, base character, gene-3
  set g-ave-C1-b4   0         ;; c1, base character, gene-4
  set g-ave-C1-b5   0         ;; c1, base character, gene-5
  set g-ave-C1-b6   0         ;; c1, base character, gene-6
  set g-ave-C1-b7   0         ;; c1, base character, gene-7

  set g-ave-c1-e0   0         ;; c1, exponent character, gene-0
  set g-ave-c1-e1   0         ;; c1, exponent character, gene-1
  set g-ave-c1-e2   0         ;; c1, exponent character, gene-2
  set g-ave-c1-e3   0         ;; c1, exponent character, gene-3
  set g-ave-c1-e4   0         ;; c1, exponent character, gene-4
  set g-ave-c1-e5   0         ;; c1, exponent character, gene-5
  set g-ave-c1-e6   0         ;; c1, exponent character, gene-6
  set g-ave-c1-e7   0         ;; c1, exponent character, gene-7

  set g-ave-C1-s0   0         ;; c1, strength character, gene-0
  set g-ave-C1-s1   0         ;; c1, strength character, gene-1
  set g-ave-C1-s2   0         ;; c1, strength character, gene-2
  set g-ave-C1-s3   0         ;; c1, strength character, gene-3
  set g-ave-C1-s4   0         ;; c1, strength character, gene-4
  set g-ave-C1-s5   0         ;; c1, strength character, gene-5
  set g-ave-C1-s6   0         ;; c1, strength character, gene-6
  set g-ave-C1-s7   0         ;; c1, strength character, gene-7

  set g-ave-C1-p0   0         ;; c1, phenotypic character, gene-0
  set g-ave-C1-p1   0         ;; c1, phenotypic character, gene-1
  set g-ave-C1-p2   0         ;; c1, phenotypic character, gene-2
  set g-ave-C1-p3   0         ;; c1, phenotypic character, gene-3
  set g-ave-C1-p4   0         ;; c1, phenotypic character, gene-4
  set g-ave-C1-p5   0         ;; c1, phenotypic character, gene-5
  set g-ave-C1-p6   0         ;; c1, phenotypic character, gene-6
  set g-ave-C1-p7   0         ;; c1, phenotypic character, gene-7

  ;; For debugging the debug feature!!!  Suppressed now.
  ;; show ( word "SETUP: Debug Is " gb-debug-on )
  ;; show ( word "SETUP: Debug Status Is " gs-debug-status )
  ;; show ( word "SETUP: Step Chooser Is " gs-debug-step-chooser )
  ;; show ( word "SETUP: Flow Control Is " gb-debug-flow-on )

  set-default-shape seekers  "arrow" ;; pulled from shapes library

  ask patches
  [
    set pcolor brown
  ]

  set g-energy-entropic-index 1 ;; Entropy associated with energy distribution.
  set g-pheno-entropic-index  1 ;; Entropy associated with genetic distribution.
  set gl-ave-pheno [ 10 10 10 10 10 10 10 10 ] ;; Average phenotype.

  ;; Initialize the seekers and the patches.
  f-initialize-seekers-and-patches

  reset-ticks ;; restarts tick counter, runs setup commands within plots
  set gb-plot-data true ;; Enables all plotting calls.

  ;; This call must follow 'reset-ticks' and initialization of seekers.
  f-update-aggregates  ;; Totals and averages.

  ;; Clears unwanted zeros in plots.
  ;; clear-all-plots
  ;; setup-plots xxx

  ;; Debug controls
  ;; Boolean, in association with chooser, turns debug LOG-TO-FILE on/off
  set gb-debug-flow-on 0
  ;; Input variable to set a tick for stopping.
  set g-halt-at-tick -1

  ;; Detrivores and Decomposers not normally included in calculations of
  ;;   EROI and ETA.
  set gb-include-dnd false

  Set g-nrg-in-fruit ( sum [fruit] of patches )
  ;; ASSERT ( frb-nrg-accounts-are-all-valid )
  ;;   ( "Do-set: Nrg accounts invalid." ) -1
  LOG-TO-FILE "  Do-set: procedure completed"

  ;; end of to setup
end

;;-----------------------------------------------------------------------------|
;; Set the scenario number using the input from the chooser.

to f-set-scenario-number
  ;; This routine is to be executed by the observer.

  set g-scenario-number ge-scenario-zero  ;; default

  if( gs-scenario = "Small Beginnings" )
    [ set g-scenario-number ge-scenario-zero ]
  if( gs-scenario = "At Carrying Capacity" )
    [ set g-scenario-number ge-scenario-one ]

  ;; End f-set-scenario-number
end

;;-----------------------------------------------------------------------------|
;; Initialize a population of seekers.

to f-initialize-seekers-and-patches
  ;; This routine is to be executed by the observer.

  set g-nrg-in-system ( 0 )
  set g-no-of-patches ( count patches )

  if( g-scenario-number = ge-scenario-zero )
    [ f-initialize-scenario-zero ]
  if( g-scenario-number = ge-scenario-one )
    [ f-initialize-scenario-one ]

  ;; Nrg accounting
  set g-nrg-in-agents ( sum [nrg] of seekers )
  set g-nrg-in-system ( g-nrg-in-system + g-nrg-in-agents )

  ;; Place more energy into patches.
  ask patches
  [
    let random-number ( random-float 1 )
    if( random-number < g-prob-of-deposit )
    [
      set fruit g-nrg-per-deposit
      set pcolor green
    ]
  ]

  set g-nrg-in-fruit ( sum [fruit] of patches )
  set g-sun-takeup-actual ( g-nrg-in-fruit )
  set g-carrying-capacity ( floor ( g-sun-takeup-actual / g-c2-epm-parm ) )
  set g-nrg-in-system ( g-nrg-in-system + g-nrg-in-fruit )

  ;; End of f-initialize-seekers-and-patches
end

;;-----------------------------------------------------------------------------|
;; Calculate the strengths and phenotypic values.

to f-find-strens-n-phenos
  ;; This routine is to be executed by a seeker.

  ;; It uses the second example of the map feature.
  ;; Examples of the map feature.
  ;; show (map + [1 2 3] [2 4 6])
  ;; => [3 6 9]
  ;; show (map [?1 + ?2 = ?3]
  ;;           [1 2 3]
  ;;           [2 4 6]
  ;;           [3 5 9])
  ;; => [true false true]

  ;; Compute the strength as S=B^(G+L).
  set c1-stren ( map [?1 ^ ?2]
                     c1-bases
                     c1-expos )
  ;; Compute the phenotypic character as Pi=100*(Si/sum(Sj)).
  set c1-pheno
    ( map [?1 * ?2 / ?3]
          ( n-values 8 [100] )
          c1-stren
          ( n-values 8 [sum c1-stren] ) )
  ;; End of f-find-strens-n-phenos
end

;;-----------------------------------------------------------------------------|
;; Initialize scenario-zero.

to f-initialize-scenario-zero
  ;; This routine is to be executed by the observer.

  ;; This scenario is called "Small Beginnings".  The slider
  ;;   g-seekers-at-start is used to size the initial population.  By default
  ;;   it is rather small.

  ;; In this scenario, we create a population of seekers which are all
  ;;   identical except for (a) location and (b) heading.

  create-seekers g-seekers-at-start
  [
    f-initialize-new-seeker

    ;; Set the heading as one of the 8 allowed headings.
    set heading ( item ( random 8 ) gl-heading-list )

    set color RED
    set age ( random RAT ) ;; Age is random with uniform distribution.
    set nrg ( random RET ) ;; Nrg is random with uniform distribution.
    ;; All start with varied age and nrg level to reduce transient time.

    ;; Genetic characters.
    set c1-bases [ 2 2 2 2 2 2 2 2 ]  ;; 8 unbiased bases
    set c1-expos [ 0 0 0 0 0 0 0 0 ]  ;; 8 unbiased exponents

    ;; Calculate the strengths and phenotypic characters.
    f-find-strens-n-phenos

    LOG-TO-FILE ( word "  Do-set: C1-bases - " c1-bases )
    LOG-TO-FILE ( word "  Do-set: c1-expos - " c1-expos )
    LOG-TO-FILE ( word "  Do-set: c1-stren - " c1-stren )
    LOG-TO-FILE ( word "  Do-set: c1-pheno - " c1-pheno )

    ;; Move each agent to a random point.
    setxy random-xcor random-ycor

  ]  ;; End of create.

  ;; End of f-initialize-scenario-zero
end

;;-----------------------------------------------------------------------------|
;; Initialize a single seeker.

to f-initialize-new-seeker
  ;; This routine is to be executed by a seeker.

  ;; BUILT-IN ATTRIBUTES
  ;; who         ;; set automatically
  ;; heading     ;; direction of motion
  ;; xcor        ;; min-pxcor <= xcor < max-pxcor
  ;; ycor        ;; min-pxcor <= xcor < max-pxcor
  ;; pen-mode    ;; "up" or "down"
  ;; pen-size    ;; in pixels
  ;; size        ;; size relative to a patch, default is 1

  ;; USER-DETERMINED ATTRIBUTES
  ;; These two are re-initialized specifically for some scenarios.
  set color RED

  ;; The biophysical body function genes are static in this model.
  ;; Load chromosome 2 with the parameters from sliders.
  set DAT g-c2-dat-parm
  set DET g-c2-det-parm
  set RAT g-c2-rat-parm
  set RET g-c2-ret-parm
  set EPM g-c2-epm-parm
  set EPA g-c2-epa-parm

  ;; Associated with seeker dynamics.
  set mas-who -1                 ;; serial number of parent seeker.
  ;; age and nrg are set in group initialization routine.
  set cause-of-death ge-cod-none ;; for statistical purposes.

  ;; Set the logic trigger flags.
  set b-is-ready-to-move      1 ;; i.e. true
  set b-is-ready-to-reproduce 0 ;; i.e. false
  set b-is-ready-to-die       0 ;; i.e. false

  ;; Variables for calculating individual EROI and ETA.
  set ind-nrg-returned g-dt-for-ind-stats ;; Numerator of EROI - an aggregate
  set ind-nrg-invested g-dt-for-ind-stats ;; Denominator of EROI - an aggregate
  set ind-nrg-benefits ( ind-nrg-returned - ind-nrg-invested )
  set ind-eroi                0 ;; Nrg returned on nrg invested = (I/C)
  set ind-eta                -5 ;; individual efficiency        = (B/I)
  set l-ind-er ( n-values g-dt-for-ind-stats [0] ) ;; Delta ERs = B of B/C
  set l-ind-ei ( n-values g-dt-for-ind-stats [0] ) ;; Delta EIs = C of B/C
  set ind-eroi-tick-counter g-dt-for-ind-stats ;; For tracking time up to delta T.

  ;; Life-time efficiency (lte) variables.
  set lte-er             0  ;; Energy returned (harvested) per lifetime
  set lte-ei             0  ;; Energy invested (spent) per lifetime
  set lte-eta           -5  ;; Life-time efficiency - eta
  set lte-eroi           0  ;; Life-time efficiency - eroi

  ;; end f-initialize-new-seeker
end

;;-----------------------------------------------------------------------------|
;; Initialize scenario-one.

to f-initialize-scenario-one
  ;; This routine is to be executed by the observer.

  ;; This scenario is called "At Carrying Capacity".  The slider
  ;;   g-seekers-at-start is ignored.  Instead, I calculate the maximum
  ;;   carrying capacity, and start with that many seekers.

  ;; In this scenario, we create a population of seekers which are all
  ;;   identical except for (a) location and (b) heading.

  let estimated-sunshine-takeup
    ( g-no-of-patches * g-nrg-per-deposit * g-prob-of-deposit )
  set g-carrying-capacity
    ( floor ( estimated-sunshine-takeup / g-c2-epm-parm ) )

  create-seekers g-carrying-capacity
  [
    f-initialize-new-seeker

    ;; Set the heading as one of the 8 allowed headings.
    set heading ( item ( random 8 ) gl-heading-list )

    set color RED
    set age ( random RAT ) ;; Age is random with uniform distribution.
    set nrg ( random RET ) ;; Nrg is random with uniform distribution.
    ;; All start with varied age and nrg level to reduce transient time.

    ;; Genetic characters.
    set c1-bases [ 2 2 2 2 2 2 2 2 ]  ;; 8 unbiased bases
    set c1-expos [ 0 0 0 0 0 0 0 0 ]  ;; 8 unbiased exponents

    ;; Calculate the strengths and phenotypic characters.
    f-find-strens-n-phenos

    LOG-TO-FILE ( word "  Do-set: C1-bases - " c1-bases )
    LOG-TO-FILE ( word "  Do-set: c1-expos - " c1-expos )
    LOG-TO-FILE ( word "  Do-set: c1-stren - " c1-stren )
    LOG-TO-FILE ( word "  Do-set: c1-pheno - " c1-pheno )

    ;; Move each agent to a random point.
    setxy random-xcor random-ycor

  ]  ;; End of create.

  ;; End of f-initialize-scenario-one
end

;;-----------------------------------------------------------------------------|
;; SECTION D – GO OR MAIN-LOOP PROCEDURE( S )
;;-----------------------------------------------------------------------------|

;;-----------------------------------------------------------------------------|
;; The go button

to go
  ;; This routine is to be executed by the observer.

  ;; Stop codes:
  ;; All stop decisions must be here in the 'go' procedure, as it causes an
  ;;   exit from the current procdure only.

  ;; XXX Special stop code for lte statistics.
  ;; if( g-dbr-stat-count >= g-max-for-lte-stats )
  ;; [
  ;;   stop
  ;; ]

  if( g-halt-at-tick = ticks  )
  [
    set g-halt-at-tick -1
    stop
  ]

  let b-should-stop-now false
  if( count turtles <= 0 ) [ set b-should-stop-now true ]
  if( b-should-stop-now = true )
  [
    stop
  ]

  ;; MANUAL CHANGE FOR DEBUG
  ;; If needed, each check for validity can be enabled between steps.
  ;; They have been suppressed (turned into comments) for the sake
  ;;   of speed of execution, but can be re-enabled if a bug has
  ;;   somehow been re-introduced.
  ;; A single call to the validity check has been left active inside of the
  ;;   Do-Post-Tick step.  If it flags a problem, re-activate these to
  ;;   narrow down where the problem starts.

  ;; Major steps or functions, done once per tick, in order of execution.
  do-pre-tick
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-pre-tick." ) ]

  do-energize
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-energize." ) ]

  do-move
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-move." ) ]

  do-feed
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: do-feed." ) ]

  do-reproduce
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-reproduce." ) ]

  do-die
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-die." ) ]

  do-post-tick
  ;; if( frb-agents-are-all-valid = false )
  ;;   [ LOG-TO-FILE ( word "Agents failed validity test: Do-post-tick." ) ]
end

;;-----------------------------------------------------------------------------|
;; D1 - do-pre-tick procedure( s )
;;-----------------------------------------------------------------------------|

to do-pre-tick
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "pre-tick" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-pre-tick: Debug on.; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; Enter all commands that need to be done before a tick begins.
  ;; Supressed. f-update-aggregates

  ;; Advance the tick counter by 1 tick.
  ifelse( gb-plot-data = true )
  [
    ;; Advance the ticks by one and update the plots.
    tick
    ;; 'tick' is exactly the same as 'update-plots' except that the tick counter
    ;;   is incremented before the plot commands are executed.
  ]
  ;; else
  [
    ;; Advance ticks by one but do not update the plots.
    tick-advance 1
  ]
  ;; End else

  ;; Once the data is plotted, the per-tick counts can be cleared.
  ;; List to hold counts of cause of death.
  set gl-causes-of-death-per-tick   ( n-values 6 [0] )

  ;; Global EROI system-wide calculations.
  ifelse( length gl-sys-nrg-returned <= g-dt-for-ind-stats )
  [
    ;; Append a zero for new data.
    set gl-sys-nrg-returned ( lput 0 gl-sys-nrg-returned ) ;; List of changes.
    set gl-sys-nrg-invested ( lput 0 gl-sys-nrg-invested ) ;; List of changes.
  ]
  ;; Else
  [
    ;; Remove old data
    set gl-sys-nrg-returned ( butfirst gl-sys-nrg-returned ) ;; List of changes.
    set gl-sys-nrg-invested ( butfirst gl-sys-nrg-invested ) ;; List of changes.
    ;; Append a zero for new data.
    set gl-sys-nrg-returned ( lput 0 gl-sys-nrg-returned ) ;; List of changes.
    set gl-sys-nrg-invested ( lput 0 gl-sys-nrg-invested ) ;; List of changes.
  ]

  ;; Reset the scenario number, in case the chooser has been changed.
  f-set-scenario-number

  ;; Clear the per-tick data for energy sinks.
  ;; This call must happen before the seeker population is stabilized.
  set gl-sinks-per-tick ( n-values 5 [0] )

  ask seekers [ set age ( age + 1 ) ]
  LOG-TO-FILE ( word "  Do-pre-tick: Seekers aged." )

  LOG-TO-FILE ( word "  Do-pre-tick: Halt at tick - " g-halt-at-tick  )
  LOG-TO-FILE ( word "  Do-pre-tick: Current tick - " ticks )

  LOG-TO-FILE "  Do-pre-tick: Routine completed."

  ;; End of do-pre-tick
end

;;-----------------------------------------------------------------------------|
;; D2 – do-energize procedure(s)
;;-----------------------------------------------------------------------------|

to do-energize
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "energize" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-energize: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; Make a list of the patches that are without fruit (without nrg)
  let empty-patch-list ( patches with [fruit = 0] )

  ;; Record the status of the patches, prior to energizing.
  set g-no-of-empty-patches ( count empty-patch-list )
  set g-no-of-dales ( g-no-of-patches - g-no-of-empty-patches )
  set g-sun-takeup-actual 0

  ;; Use the probability of deposit to determine if fruit is added.
  ask empty-patch-list
  [
    let random-number ( random-float 1 )
    let threshold ( g-prob-of-deposit )
    if ( random-number <= threshold )
    [
      set fruit ( fruit + g-nrg-per-deposit )
      set pcolor green
      ;; Record in system nrg accounts
      set g-nrg-in-fruit  ( g-nrg-in-fruit + g-nrg-per-deposit )
      set g-sun-takeup-actual ( g-sun-takeup-actual + g-nrg-per-deposit )
    ]
  ]

  ;; Estimate the carrying capacity, based on the take-up rate this tick.
  let mean-epm ( mean [epm] of seekers )
  set g-carrying-capacity ( floor ( g-sun-takeup-actual / mean-epm ) )
  set g-nrg-in-system ( g-nrg-in-system + g-sun-takeup-actual )

  ;; Supressed. f-update-aggregates

  LOG-TO-FILE "  Do-energize: procedure completed"

  ;; End of do-energize
end

;;-----------------------------------------------------------------------------|
;; D3 – do-move procedure(s)
;;-----------------------------------------------------------------------------|

to do-move
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "move" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-move: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; The seekers move.
  ask seekers
  [
    if( b-is-ready-to-move = 1 )
    [
      f-seeker-moves
    ]  ;; End if( b-is-ready-to-move = 1 )
  ]  ;; End ask seekers

  ;; Supressed. f-update-aggregates

  LOG-TO-FILE "  Do-move: procedure completed"
end

;;-----------------------------------------------------------------------------|
;; A seeker moves according to genes and heuristics.

to f-seeker-moves
  ;; This routine is to be executed by a seeker.

  ;; When a seeker moves it expends energy out of its pool of nrg.
  ;; Determine if this seeker has sufficient nrg to move.
  ifelse ( nrg >= EPM )
  [
    ;; Establish a heading.
    f-seeker-sets-heading

    ;; Step forward
    forward 1

    ;; Expend the nrg to the sink.
    f-store-data-in-sink ge-sinktype-move-EPM EPM
    set nrg ( nrg - EPM )

    ;; Record the expenditure in the stats.
    set g-nrg-in-system ( g-nrg-in-system - EPM )
    set g-nrg-in-agents ( g-nrg-in-agents - EPM )

    ;; Record the expenditure in the EROI variables
    f-record-ei-for-eroi EPM

    set b-is-ready-to-move 1
    ;; set b-is-ready-to-die 0
  ]
  ;; Else
  [
    ;; The seeker is marked for death, and nrg is removed.
    ;; It will die and be removed when do-die is executed.
    f-store-data-in-sink ge-sinktype-move-EPM nrg
    set g-nrg-in-system ( g-nrg-in-system - nrg )
    set g-nrg-in-agents ( g-nrg-in-agents - nrg )

    ;; Record the expenditure in the EROI variables
    f-record-ei-for-eroi nrg

    set nrg 0
    set cause-of-death ge-cod-hunger
    set b-is-ready-to-move 0
    set b-is-ready-to-die 1
  ]
  ;; End else

  LOG-TO-FILE ( word "  Do-move: S(heading,nrg,move-flag,die-flag) - ("
    heading ","
    floor nrg ","
    b-is-ready-to-move","
    b-is-ready-to-die ")" )

  ;; End of f-seeker-moves
end

;;-----------------------------------------------------------------------------|
;; A seeker sets a heading using c1-pheno.

to f-seeker-sets-heading
  ;; This routine is to be executed by a seeker.

    ;; The agent will consult its phenotypic characters, to determine the
    ;;   best direction for the next heading.  It is blind, and cannot sense
    ;;   other agents, or patches of fruit.  So the only guidance it has is
    ;;   the genetic information received from its mother.

    ;; Take note of the current heading.
    let old-heading heading

    ;; DECIDE HOW MUCH TO TURN AS DELTA-HEADING.
    ;; Add up the indicators.
    let sum-of-phenos ( round ( sum c1-pheno ) )
    LOG-TO-FILE ( word "  Do-move: Phenos          - " c1-pheno )
    LOG-TO-FILE ( word "  Do-move: Summed Phenos   - " sum-of-phenos )
    ;; Each pheno is derived from genes plus learnings.  The size of
    ;;   the pheno creates a proportional target interval in the sum.
    ;;   Choose an interval (i.e. choose a pheno) by getting a random number.
    let random-number ( random-float sum-of-phenos )
    LOG-TO-FILE ( word "  Do-move: Random Number   - " random-number )
    ;; The random-number must fall between two sequential pheno aggregates.
    ;; E.g if the random-number is 50%, and the first two pheno numbers
    ;;   are 13% and 25% (+=38%) then that sum is less than 50%.  If the
    ;;   next pheno is 20%, then the aggregate is 58%, which is bigger
    ;;   than 50%.  So it falls between the 2nd and 3rd aggregate of the
    ;;   phenos.  The third interval then is selected "randomly" with
    ;;   probability determined by its relative size, among all phenos.
    ;;   Due to zero-based indexing, the correct index is 3-1 = 2.

    let counter 0
    let good-index -1
    let this-pheno 0
    let this-sum 0
    let next-sum 0
    while [ counter < 8 ]  ;; Do not overshoot
    [
      LOG-TO-FILE ( word "  Do-move: Counter         - " counter )
      set this-pheno ( item counter c1-pheno )
      LOG-TO-FILE ( word "  Do-move: This sum        - " this-sum )
      LOG-TO-FILE ( word "  Do-move: Pheno           - " this-pheno )
      set next-sum ( this-pheno + this-sum )
      LOG-TO-FILE ( word "  Do-move: Next sum        - " next-sum )
      if ( ( random-number >= this-sum ) and
           ( random-number < next-sum  ) )
      [
        set good-index counter
        LOG-TO-FILE ( word "  Do-move: Selected gene   - " good-index )
      ]
      set this-sum next-sum
      set counter ( counter + 1 )
    ]
    let heading-delta ( item good-index gl-heading-list )
    LOG-TO-FILE ( word "  Do-move: Old heading     - " heading )

    ;; Set the new heading
    set heading ( heading + heading-delta )
    LOG-TO-FILE ( word "  Do-move: New heading     - " heading )

  ;; End of f-seeker-sets-heading
end

;;-----------------------------------------------------------------------------|
;; Store data in the lists of sinks.

to f-store-data-in-sink [ sinktype value ]
  ;; This routine is to be executed by anyone.

  ;; Record it in the per-tick list.
  let old-value ( item sinktype gl-sinks-per-tick )
  let new-value ( old-value + value )
  set gl-sinks-per-tick ( replace-item sinktype gl-sinks-per-tick new-value )

  ;; Record it in the cumulative list.
  set old-value ( item sinktype gl-sinks-cumulative )
  set new-value ( old-value + value )
  set gl-sinks-cumulative
    ( replace-item sinktype gl-sinks-cumulative new-value )

  ;; end of f-store-data-in-sink
end

;;-----------------------------------------------------------------------------|
;; Increment the count in the lists of causes of death.

to f-increment-cod-list [ breedtype codtype ]
  ;; This routine is to be executed by anyone.

  ;; Record it in the per-tick list.
  let old-count ( item codtype gl-causes-of-death-per-tick )
  let new-count ( old-count + 1 )
  set gl-causes-of-death-per-tick
    ( replace-item codtype gl-causes-of-death-per-tick new-count )

  ;; Record it in the cumulative list.
  set old-count ( item codtype gl-causes-of-death-cumulative )
  set new-count ( old-count + 1 )
  set gl-causes-of-death-cumulative
    ( replace-item codtype gl-causes-of-death-cumulative new-count )

  ;; End of f-increment-cod-list
end

;;-----------------------------------------------------------------------------|
;; Record the 'energy invested' component of EROI calculation.

to f-record-ei-for-eroi [eroi-ei]
  ;; This routine is to be executed by a seeker.
  ;;   It updates both individual values, and sys-wide values.

  ;; There are three associated routines:
  ;;   f-record-er-for-eroi is called by Do-feed.
  ;;   f-record-ei-for-eroi is called by Do-Move.
  ;;   f-record-ei-for-dnd-eroi is called by Do-Death.
  ;; The three routines work together to calculate individual and
  ;;   system-wide EROI and ETA.

  ;; NOTE: EROI is ER/EI, that is Benefits over Costs, or (B/C).
  ;;       ETA is (ER-EI)/ER, that is Benefits over Income, or (B/I).

  ;; LOG-TO-FILE ( word "  Do-move: Eroi-counter - " ind-eroi-tick-counter )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-returned - " ind-nrg-returned )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-invested - " ind-nrg-invested )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-benefits - " ind-nrg-benefits )
  ;; LOG-TO-FILE ( word "  Do-move: L-ind-er     - " l-ind-er )
  ;; LOG-TO-FILE ( word "  Do-move: L-ind-ei     - " l-ind-ei )

  ;; LOG-TO-FILE ( word "  Do-move: Lte-er       - " lte-er )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-ei       - " lte-ei )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-eta      - " lte-eta )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-eroi     - " lte-eroi )

  ;; First, record it in the system-wide data.
  LOG-TO-FILE ( word "  Do-move: g-sys-ei was    - " gl-sys-nrg-invested )
  let last-index ( ( length gl-sys-nrg-invested ) - 1 )
  let old-value ( last gl-sys-nrg-invested )
  let new-value ( old-value + eroi-ei )
  set gl-sys-nrg-invested
    ( replace-item last-index gl-sys-nrg-invested new-value )
  LOG-TO-FILE ( word "  Do-move: g-sys-ei is now - " gl-sys-nrg-invested )

  ;; Now record it in the individual data for this seeker.
  ;; Check to determine whether we are only appending data to the list,
  ;;   or we are dropping old data and appending new data.
  ifelse ( ind-eroi-tick-counter < g-dt-for-ind-stats )
  [
    ;; Case of appending new data only.
    ;; Increment the counter - done only in move-related function.
    set ind-eroi-tick-counter ( ind-eroi-tick-counter + 1 )
    ;; Append new entry to last of l-ind-ei.
    set l-ind-ei ( lput eroi-ei l-ind-ei )
    ;; Append a place-holder zero to l-ind-er.
    set l-ind-er ( lput 0 l-ind-er )
  ]
  ;; Else
  [
    ;; Case of dropping/appending data
    ;; Remove oldest entry.
    set l-ind-ei ( butfirst l-ind-ei )
    ;; Append new entry to last of l-ind-ei
    set l-ind-ei ( lput eroi-ei l-ind-ei )

    ;; Adjust l-ind-er, removing oldest and appending a place-holder zero.
    ;; Remove oldest entry.
    set l-ind-er ( butfirst l-ind-er )
    ;; Append zero to last of l-ind-er
    set l-ind-er ( lput 0 l-ind-er )
  ]  ;; End else dropping/appending

  ;; Life-time efficiency (lte) stats were added later.
  ;;   Lte data is aggregated over the entire life of the seeker.
  set lte-ei ( lte-ei + eroi-ei )  ;; Note the added investment.

  ;; Re-calculate the seekers stats.
  set ind-nrg-invested ( sum l-ind-ei )
  set ind-nrg-benefits ( ind-nrg-returned - ind-nrg-invested )

  ifelse (ind-nrg-invested > 0)
    [ set ind-eroi ( ind-nrg-returned / ind-nrg-invested ) ] ;; (I/C)
    [ set ind-eroi 0 ] ;; (I/C)

  ifelse (ind-nrg-returned > 0)
    [ set ind-eta ( ind-nrg-benefits / ind-nrg-returned ) ]  ;; (B/I)
    [ set ind-eta -5 ]  ;; (B/I)

  ;; Re-calculate the life-time-efficiency stats
  ifelse (lte-ei > 0)
    [ set lte-eroi ( lte-er / lte-ei ) ]              ;; (I/C)
    [ set lte-eroi 0 ]              ;; (I/C)

  ifelse (lte-er > 0)
    [ set lte-eta ( ( lte-er - lte-ei ) / lte-er ) ]  ;; (B/I)
    [ set lte-eta -5 ]  ;; (B/I)

  ;; LOG-TO-FILE ( word "  Do-move: Eroi-counter - " ind-eroi-tick-counter )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-returned - " ind-nrg-returned )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-invested - " ind-nrg-invested )
  ;; LOG-TO-FILE ( word "  Do-move: Nrg-benefits - " ind-nrg-benefits )
  ;; LOG-TO-FILE ( word "  Do-move: L-ind-er     - " l-ind-er )
  ;; LOG-TO-FILE ( word "  Do-move: L-ind-ei     - " l-ind-ei )

  ;; LOG-TO-FILE ( word "  Do-move: Lte-er       - " lte-er )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-ei       - " lte-ei )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-eta      - " lte-eta )
  ;; LOG-TO-FILE ( word "  Do-move: Lte-eroi     - " lte-eroi )

  ;; End of f-record-ei-for-eroi
end

;;-----------------------------------------------------------------------------|
;; Record the 'energy invested' component of EROI calculation.

to f-record-ei-for-dnd-eroi [eroi-ei]
  ;; This routine is to be executed by a seeker.
  ;;   It updates sys-wide values only, since the activity of decomposers
  ;;   and detrivores should not affect individual statistics.

  ;; There are three associated routines:
  ;;   f-record-er-for-eroi is called by Do-feed.
  ;;   f-record-ei-for-eroi is called by Do-Move.
  ;;   f-record-ei-for-dnd-eroi is called by Do-Death.
  ;; The three routines work together to calculate individual and
  ;;   system-wide EROI and ETA.

  ;; NOTE: EROI is ER/EI, that is Benefits over Costs, or (B/C).
  ;;       ETA is (ER-EI)/ER, that is Benefits over Income, or (B/I).

  LOG-TO-FILE ( word "  Do-death: g-sys-ei was   - " gl-sys-nrg-invested )
  ;; First, record it in the system-wide data.
  let last-index ( ( length gl-sys-nrg-invested ) - 1 )
  let old-value ( last gl-sys-nrg-invested )
  let new-value ( old-value + eroi-ei )
  set gl-sys-nrg-invested
    ( replace-item last-index gl-sys-nrg-invested new-value )
  LOG-TO-FILE ( word " Do-death: g-sys-ei is now - " gl-sys-nrg-invested )

  ;; End of f-record-ei-for-dnd-eroi
end

;;-----------------------------------------------------------------------------|
;; D4 – do-feed procedure(s)
;;-----------------------------------------------------------------------------|

to do-feed
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "feed" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-feed: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; Agents feed on fruit found in patches.
  ask seekers
  [
    let this-patch patch-here  ;; handle to the patch under the seeker.
    let nrg-available ( [fruit] of this-patch )
    if ( ( nrg < ( EPA - g-nrg-per-deposit ) ) and
         ( nrg-available > 0 ) )
    [
      ;; Case of there is food to eat.
      ;; Seeker eats.
      set nrg ( nrg + nrg-available )
      set g-nrg-in-agents ( g-nrg-in-agents + nrg-available )
      f-record-er-for-eroi nrg-available
      ask this-patch
      [
        set fruit 0
        set g-nrg-in-fruit ( g-nrg-in-fruit - nrg-available )
        set pcolor brown
      ]
    ]
  ]  ;; End of ask seekers.

  ;; Supressed. f-update-aggregates

  LOG-TO-FILE "  Do-feed: procedure completed"

  ;; End Do-feed procedure.
end

;;-----------------------------------------------------------------------------|
;; Record the 'energy returned' component of EROI calculation.

to f-record-er-for-eroi [eroi-er]
  ;; This routine is to be executed by a seeker.
  ;;   It updates both individual values, and sys-wide values.

  ;; There are three associated routines:
  ;;   f-record-er-for-eroi is called by Do-feed.
  ;;   f-record-ei-for-eroi is called by Do-Move.
  ;;   f-record-ei-for-dnd-eroi is called by Do-Death.
  ;; The three routines work together to calculate individual and
  ;;   system-wide EROI and ETA.

  ;; NOTE: EROI is ER/EI, that is Benefits over Costs, or (B/C).
  ;;       ETA is (ER-EI)/ER, that is Benefits over Income, or (B/I).

  ;; LOG-TO-FILE ( word "  Do-feed: Eroi-counter - " ind-eroi-tick-counter )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-returned - " ind-nrg-returned )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-invested - " ind-nrg-invested )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-benefits - " ind-nrg-benefits )
  ;; LOG-TO-FILE ( word "  Do-feed: L-ind-er     - " l-ind-er )
  ;; LOG-TO-FILE ( word "  Do-feed: L-ind-ei     - " l-ind-ei )

  ;; LOG-TO-FILE ( word "  Do-feed: Lte-er       - " lte-er )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-ei       - " lte-ei )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-eta      - " lte-eta )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-eroi     - " lte-eroi )

  ;; First, record it in the system-wide data.
  ;; LOG-TO-FILE ( word "  Do-feed: g-sys-er was    - " gl-sys-nrg-returned )
  let last-index ( ( length gl-sys-nrg-returned ) - 1 )
  let old-value ( last gl-sys-nrg-returned )
  let new-value ( old-value + eroi-er )
  set gl-sys-nrg-returned
    ( replace-item last-index gl-sys-nrg-returned new-value )
  ;; LOG-TO-FILE ( word "  Do-feed: g-sys-er is now - " gl-sys-nrg-returned )

  ;; Now, record it in the individual data.
  ;; DO NOT increment the counter here - done only in move-related function.
  ;; set ind-eroi-tick-counter ( ind-eroi-tick-counter + 1 )
  ;; Remove the place-holder zero, put there in the move-related routine.
  set l-ind-er ( butlast l-ind-er )
  ;; Append new entry to last of l-ind-er.
  set l-ind-er ( lput eroi-er l-ind-er )

  ;; Update the life-time-efficiency (lte) stats.
  set lte-er ( lte-er + eroi-er )

  ;; Re-calculate the seeker's stats.
  set ind-nrg-returned ( sum l-ind-er )
  set ind-nrg-benefits ( ind-nrg-returned - ind-nrg-invested )

  ifelse (ind-nrg-invested > 0)
    [ set ind-eroi ( ind-nrg-returned / ind-nrg-invested ) ]  ;; (I/C)
    [ set ind-eroi 0 ]  ;; (I/C)

  ifelse (ind-nrg-returned > 0)
    [ set ind-eta ( ind-nrg-benefits / ind-nrg-returned ) ]   ;; (B/I)
    [ set ind-eta -5 ]   ;; (B/I)

  ;; Recalculate the life-time stats.
  ifelse (lte-ei > 0)
    [ set lte-eroi ( lte-er / lte-ei ) ]
    [ set lte-eroi 0 ]

  ifelse (lte-er > 0)
    [ set lte-eta ( ( lte-er - lte-ei ) / lte-er ) ]
    [ set lte-eta -5 ]

  ;; LOG-TO-FILE ( word "  Do-feed: Eroi-counter - " ind-eroi-tick-counter )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-returned - " ind-nrg-returned )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-invested - " ind-nrg-invested )
  ;; LOG-TO-FILE ( word "  Do-feed: Nrg-benefits - " ind-nrg-benefits )
  ;; LOG-TO-FILE ( word "  Do-feed: L-ind-er     - " l-ind-er )
  ;; LOG-TO-FILE ( word "  Do-feed: L-ind-ei     - " l-ind-ei )

  ;; LOG-TO-FILE ( word "  Do-feed: Lte-er       - " lte-er )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-ei       - " lte-ei )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-eta      - " lte-eta )
  ;; LOG-TO-FILE ( word "  Do-feed: Lte-eroi     - " lte-eroi )

  ;; End of f-record-er-for-eroi
end

;;-----------------------------------------------------------------------------|
;; D5 – do-reproduce procedure(s)
;;-----------------------------------------------------------------------------|

to do-reproduce
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "reproduce" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-rep: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ask seekers
  [
    f-set-seeker-repro-flag
    f-reproduce-seeker-by-fission
  ]

  ;; Supressed. f-update-aggregates

  LOG-TO-FILE "  Do-rep: procedure completed"
end

;;-----------------------------------------------------------------------------|
;; f-set-seeker-repro-flag

to f-set-seeker-repro-flag
  ;; This routine is to be executed by a seeker.

  set b-is-ready-to-reproduce 1        ;; i.e. true is the default.
  if( nrg < RET )
    [ set b-is-ready-to-reproduce 0 ]  ;; i.e. false due to lack of health.

  if( age < RAT )
    [ set b-is-ready-to-reproduce 0 ]  ;; i.e. false due to lack of maturity.

  if( b-is-ready-to-reproduce = 1 )
  [
    LOG-TO-FILE
      ( word "  Do-rep: S(age,nrg,rep-flag) - ("
        age "," floor nrg  "," b-is-ready-to-reproduce ")" )
  ]

  ;; End f-set-seeker-repro-flag
end

;;-----------------------------------------------------------------------------|
;; A seeker reproduces via fission, one mother having two daughters.

to f-reproduce-seeker-by-fission
  ;; This routine is to be executed by a seeker.

  if( b-is-ready-to-reproduce = 1 )   ;; 1 = true
  [
    LOG-TO-FILE ( word "  Do-rep: seeker Ma - " who )

    ;; This mother is dying due to reproduction.  Her lte-eroi and lte-eta
    ;;   values need to be recorded in the death statistics.
    ;; Record the eroi and eta data of mother before reproduction by fission.
    if( g-dbr-stat-count >= g-max-for-lte-stats )
    [
      ;; Remove old data for "death by repro" (dbr).
      set gl-lte-eroi-dbr ( butfirst gl-lte-eroi-dbr )
      set gl-lte-eta-dbr ( butfirst gl-lte-eta-dbr )
      set g-dbr-stat-count ( g-dbr-stat-count - 1 )
    ]
    set gl-lte-eroi-dbr ( lput lte-eroi gl-lte-eroi-dbr )
    set gl-lte-eta-dbr ( lput lte-eta gl-lte-eta-dbr )
    set g-dbr-stat-count ( g-dbr-stat-count + 1 )
    set gl-lte-eroi-all
      ( sentence gl-lte-eroi-dbh gl-lte-eroi-dbo gl-lte-eroi-dbr )
    set gl-lte-eta-all
      ( sentence gl-lte-eta-dbh gl-lte-eta-dbo gl-lte-eta-dbr )

    ;; Let statements for fission.
    let mother self
    let mothers-who who
    let mothers-patch patch-here

    let first-share-of-nrg floor( nrg / 2 )
    let second-share-of-nrg ( nrg - first-share-of-nrg )

    ;; Record the nrg as passed on to daughters.
    f-store-data-in-sink ge-sinktype-repro-RET nrg

    let daughter-count 0
    ask mothers-patch
    [
      sprout-seekers 2
      [
        set daughter-count ( daughter-count + 1 )
        LOG-TO-FILE ( word "  Do-rep: seeker D" daughter-count " - " who )
        f-initialize-new-seeker
        set color ( [color] of mother )

        ;; Copy the C1 genetic/learned material.
        set c1-bases ( [c1-bases] of mother )
        set c1-expos ( [c1-expos] of mother )
        set c1-stren ( [c1-stren] of mother )
        set c1-pheno ( [c1-pheno] of mother )

        ;; C2 genes are static.
        set DAT ( [DAT] of mother )
        set DET ( [DET] of mother )
        set RAT ( [RAT] of mother )
        set RET ( [RET] of mother )
        set EPM ( [EPM] of mother )
        set EPA ( [EPA] of mother )

        ;; Note the mother of this daughter.
        set mas-who ( [who] of mother )
        set age 0

        ifelse ( daughter-count = 1 )
        [ set nrg first-share-of-nrg ]
        [ set nrg second-share-of-nrg ]

        set cause-of-death          0
        set b-is-ready-to-move      1
        set b-is-ready-to-reproduce 0
        set b-is-ready-to-die       0

        ;; Variables for calculating individual EROI and ETA.
        ;; All inherited from mother.
        set ind-nrg-returned ( [ind-nrg-returned] of mother )
        set ind-nrg-invested ( [ind-nrg-invested] of mother )
        set ind-nrg-benefits ( [ind-nrg-benefits] of mother )
        set ind-eroi         ( [ind-eroi] of mother )
        set ind-eta          ( [ind-eta]  of mother )
        set l-ind-er         ( [l-ind-er] of mother )
        set l-ind-ei         ( [l-ind-ei] of mother )
        set ind-eroi-tick-counter ( [ind-eroi-tick-counter] of mother )

        ;; Variables for calculating life-time-efficiencies EROI and ETA.
        set lte-ei 0
        set lte-er 0
        set lte-eta 0
        set lte-eroi 0

        f-mutate-new-seeker
      ]
    ]

    ;; Set the cause of death for the mother.
    set cause-of-death ge-cod-fission
    ;; The mother disappears after fission, leaving two daughters.
    ;; Death actually occurs in the Do-die step.

  ]

  ;; End f-reproduce-seeker-by-fission
end

;;-----------------------------------------------------------------------------|
;; A new seeker mutates, changing the genetic basis of strategies.

to f-mutate-new-seeker
  ;; This routine is to be executed by a seeker.

  ;; When a mutation is called for, one gene is mutated.  So when one or both
  ;;   switches are on, the probability that a C1 gene will mutate must
  ;;   decrease.  I could give each of C1, EPM and EPA equal probability of
  ;;   occurrence.  Since there are, in fact 8 C1 genes, (as opposed to 2
  ;;   possible C2 genes) they should get to mutate 8/10 = 80% of the time
  ;;   or more when a mutation is called for.  However, since my interest
  ;;   is NOT on the C1 genes, a dynamic that I understand well, I want the
  ;;   EPM and EPA to evolve more rapidly when called for.   For that reason,
  ;;   I have written the code to recognize the C1 chromosome, as a whole,
  ;;   as having equal status as the EPM and EPA when activated.
  ;; Given that a mutation of some sort must hapen, the probability of
  ;;   mutation of the various genes must be spread around appropriately.
  ;; The various scenarios are then:
  ;; -EPM=OFF; EPA=OFF; C1 gets 100%; EPM gets 0%;  EPA gets 0%
  ;; -EPM=OFF; EPA=ON;  C1 gets 50%;  EPM gets 0%;  EPA gets 50%
  ;; -EPM=ON;  EPA=OFF; C1 gets 50%;  EPM gets 50%; EPA gets 0%
  ;; -EPM=ON;  EPA=ON;  C1 gets 33 1/3%; EPM gets 33 1/3%; EPA gets 33 1/3%
  ;; This logic is rolled out over several calls to sub-routines.  Note that
  ;;   these percentages are conditional on determination that a mutation
  ;;   must happen for this seeker daughter in this reproductive event.

  ;; Decide if a genetic mutation is to happen.
  let random-number ( random-float 1 )
  let threshold ( g-prob-of-mutation )
  LOG-TO-FILE
    ( word "  Do-rep: PreMut (RN, TH)    - (" random-number ", " threshold ")" )
  if ( random-number <= threshold )
  [
    ;; I want only one gene to mutate when mutation is called for.  So
    ;;   I need some logic that responds to the toggles that control which
    ;;   kinds of gene mutate - i.e. gb-mutate-epm and gb-mutate-epa.
    ifelse( ( gb-mutate-epm = false ) and ( gb-mutate-epa = false ) )
    [
      ;; Case of both EPM and EPA mutation is turned off.  C1 gets 100%.
      f-mutate-c1-gene
    ]
    ;; Else
    [
      ;; Some other case.  C1 gets less than 100% probability of mutation.
      ;; Either a c1 gene mutates, or one of EPM or EPA (C2 genes) mutate.
      ;; At this point I know that at least one of EPM and EPA is to be included.
      ;; So, the competition is between two or three, with thresholds of 0.5
      ;; or 0.33333.
      set threshold ( 0.3333333333333 ) ;; Default
      if( ( gb-mutate-epm = false ) or ( gb-mutate-epm = false ) )
      [
        set threshold ( 0.5 )
      ]
      ;; Decide which type of genetic mutation is to happen.
      set random-number ( random-float 1 )
      LOG-TO-FILE
        ( word "  Do-rep: PreCxMut (RN, TH)  - (" random-number ", " threshold ")" )
      ifelse ( random-number <= threshold )
      [ f-mutate-c1-gene ]
      [ f-mutate-c2-gene ]
    ]
  ]

  ;; End of f-mutate-new-seeker
end

;;-----------------------------------------------------------------------------|
;; A seeker mutates a chromosome #1 (c1) gene.

to f-mutate-c1-gene
  ;; This routine is to be executed by a seeker.

  ;; Case of C1 mutation to be done.
  LOG-TO-FILE ( word "  Do-rep: PreC1Mut c1-bases  - " c1-bases )
  LOG-TO-FILE ( word "  Do-rep: PreC1Mut c1-expos  - " c1-expos )
  LOG-TO-FILE ( word "  Do-rep: PreC1Mut c1-stren  - " c1-stren )
  LOG-TO-FILE ( word "  Do-rep: PreC1Mut c1-pheno  - " c1-pheno )

  ;; There are 8 C1 genes.  Select the gene to be mutated.  These genes
  ;;   control the heuristic search strategy.
  let gene-to-be-mutated ( random 8 )
  LOG-TO-FILE ( word "  Do-rep: Target gene #      - " gene-to-be-mutated )

  ;; Mutate the gene base.
  let oldbase ( item gene-to-be-mutated c1-bases )
  LOG-TO-FILE ( word "  Do-rep: Old base value     - " oldbase )
  ;; Choose a factor for the base.
  let base-factor ( item (random 8) gl-base-factors )
  ;; Mutate it
  let newbase ( oldbase * base-factor )
  LOG-TO-FILE ( word "  Do-rep: Factor             - " base-factor )
  set c1-bases ( replace-item gene-to-be-mutated c1-bases newbase )
  LOG-TO-FILE ( word "  Do-rep: New base value     - " newbase )

  ;; Mutate the gene.  The gene value is an integer of either sign.
  let oldgene ( item gene-to-be-mutated c1-expos )
  LOG-TO-FILE ( word "  Do-rep: Old gene value     - " oldgene )
  ;; Decide whether it will increase or decrease in value.
  let delta ( -1 + ( 2 * ( random 2 ) ) )  ;; Either a -1 or a 1.
  LOG-TO-FILE ( word "  Do-rep: Delta              - " delta )
  let newgene ( oldgene + delta )
  set c1-expos ( replace-item gene-to-be-mutated c1-expos newgene )
  LOG-TO-FILE ( word "  Do-rep: New gene value     - " newgene )

  ;; Calculate the strengths and phenotypic characters.
  f-find-strens-n-phenos

  LOG-TO-FILE ( word "  Do-rep: AftC1Mut c1-bases  - " c1-bases )
  LOG-TO-FILE ( word "  Do-rep: AftC1Mut c1-expos  - " c1-expos )
  LOG-TO-FILE ( word "  Do-rep: AftC1Mut c1-stren  - " c1-stren )
  LOG-TO-FILE ( word "  Do-rep: AftC1Mut c1-pheno  - " c1-pheno )

  ;; End of f-mutate-c1-gene
end

;;-----------------------------------------------------------------------------|
;; A seeker mutates a Chromosome #2 (C2) gene.

to f-mutate-c2-gene
  ;; This routine is to be executed by a seeker.
  ;; To be called, at least one switch must be on.

  ;; One of two genes is to be mutated.  Either EPM or EPA.
  ;;   EPM is energy per move, and controls the rate of metabolic expenditure.
  ;;   EPA is energy per agent, and controls the maximal nrg content per agent.
  ;; Both of these genes play a role in the throughput of energy.  EPM
  ;;   has an obvious direct role, and should have great pressure put on it.
  ;;   EPA has an indirect role, and should have mild pressure put on it.
  ;;   I.e. I think EPM has a strong effect on survivability, while EPA has
  ;;   a much lesser effect.

  ;; Decide which genetic mutation is to happen.
  ;; Mutation of these genes is toggled on or off by Boolean switches.  To
  ;;   have this program called, at least one of those is on, but possibly
  ;;   both are on.
  if( gb-mutate-epa = false )
  [
    ;; Case of EPM to be mutated.
    f-mutate-epm
  ]

  if( gb-mutate-epm = false )
  [
    ;; Case of EPA to be mutated.
    f-mutate-epa
  ]

  if( ( gb-mutate-epm = true ) and ( gb-mutate-epa = true ) )
  [
    ;; Each has a 50/50 chance.
    let random-number ( random-float 1 )
    let threshold ( 0.50 )
    LOG-TO-FILE
      ( word "  Do-rep: PreC2Mut (RN, TH)  - (" random-number ", " threshold ")" )
    ifelse ( random-number <= threshold )
    [ f-mutate-epm ]
    ;; Else
    [ f-mutate-epa ]
  ]

  ;; End of f-mutate-c2-gene
end

;;-----------------------------------------------------------------------------|
;; The EPM C2 gene is to be mutated.

to f-mutate-EPM
  ;; This routine is to be executed by a seeker.

  ;; Case of mutation of EPM.
  LOG-TO-FILE ( word "  Do-rep: PreC2Mut EPM       - " EPM )

  ;; I want a variety of factors to avoid discreteness in values.
  ;; I want an unbiased chance of a rise or fall in value.
  let l-factor-list
    [ 1.01 1.01 1.01 1.01 1.02 1.02 1.04
      0.99 0.99 0.99 0.99 0.98 0.98 0.96 ]
  ;; Choose a factor.
  let factor ( item (random 14) l-factor-list )
  LOG-TO-FILE ( word "  Do-rep: Factor             - " factor )
  ;; Mutate it
  set EPM ( EPM * factor )
  LOG-TO-FILE ( word "  Do-rep: AftC2Mut EPM       - " EPM )

  ;; End of f-mutate-EPM
end

;;-----------------------------------------------------------------------------|
;; The EPA C2 gene is to be mutated.

to f-mutate-EPA
  ;; This routine is to be executed by a seeker.

  ;; Case of mutation of EPA.
  LOG-TO-FILE ( word "  Do-rep: PreC2Mut EPA       - " EPA )

  ;; I want a variety of factors to avoid discreteness in values.
  ;; I want an unbiased chance of a rise or fall in value.
  let l-factor-list
    [ 1.001 1.001 1.001 1.001 1.002 1.002 1.004
      0.999 0.999 0.999 0.999 0.998 0.998 0.996 ]
  ;; Choose a factor.
  let factor ( item (random 14) l-factor-list )
  LOG-TO-FILE ( word "  Do-rep: Factor             - " factor )
  ;; Mutate it
  set EPA ( EPA * factor )
  LOG-TO-FILE ( word "  Do-rep: AftC2Mut EPA       - " EPA )

  ;; End of f-mutate-EPA
end

;;-----------------------------------------------------------------------------|
;; D6 – do-die procedure(s)
;;-----------------------------------------------------------------------------|

to do-die
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "die" ) )
    [ set gb-debug-flow-on 1 LOG-TO-FILE "" LOG-TO-FILE word "Do-die: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  if( ( count seekers ) > 0 )
  [
    ask seekers
    [
      f-set-seeker-death-flag
      f-seeker-dies
    ]
  ]

  ;; Supressed. f-update-aggregates

  LOG-TO-FILE "  Do-die: procedure completed"
end

;;-----------------------------------------------------------------------------|
;; f-set-seeker-death-flag

to f-set-seeker-death-flag
  ;; This routine is to be executed by a seeker.

  set b-is-ready-to-die 0        ;; i.e. false, default.

  ;; If a cause of death has already been noted, it dies.
  ifelse( cause-of-death > ge-cod-none )
  [
    ;; A cause of death has been previously flagged.
    ;; This is either due to hunger (in do-move) or fission (in do-repro).
    ;; In both cases nrg has been stripped out already.
    ;; In the cases of DET and DAT, the flag is not yet set,
    ;;   and the nrg remains.
    set b-is-ready-to-die 1
  ]
  ;; Else
  [
    ;; No cause of death has been set yet.  Check basic vital signs.
    if( nrg <= DET )  ;; Death Energy Threshold.
    [
      set b-is-ready-to-die 1
      set cause-of-death ge-cod-hunger
      f-store-data-in-sink ge-sinktype-die-det nrg
      set g-nrg-in-system ( g-nrg-in-system - nrg )
      set g-nrg-in-agents ( g-nrg-in-agents - nrg )

      if( gb-include-dnd = true )
      [
        ;; Record the expenditure in the EROI variables
        f-record-ei-for-dnd-eroi nrg
      ]

      set nrg 0
    ]

    if( age > DAT )   ;; Death Age Threshold.
    [
      set b-is-ready-to-die 1
      set cause-of-death ge-cod-oldage
      f-store-data-in-sink ge-sinktype-die-dat nrg
      set g-nrg-in-agents ( g-nrg-in-agents - nrg )
      set g-nrg-in-system ( g-nrg-in-system - nrg )

      if( gb-include-dnd = true )
      [
        ;; Record the expenditure in the EROI variables
        f-record-ei-for-dnd-eroi nrg
      ]

      set nrg 0
    ]
  ]

  if( b-is-ready-to-die = 1 )
  [
    LOG-TO-FILE ( WORD "  Do-die: S(age,nrg,cod) - ("
      age ","
      nrg ","
      cause-of-death ")" )
  ]

  ;; End f-set-seeker-death-flag
end

;;-----------------------------------------------------------------------------|
;; f-seeker-dies

to f-seeker-dies
  ;; This routine is to be executed by a seeker.

  if( b-is-ready-to-die = 1 )
  [
    ;; Record the eroi and eta data before death by hunger.
    if( cause-of-death = ge-cod-hunger )
    [
      if( g-dbh-stat-count >= g-max-for-lte-stats )
      [
        ;; Remove old data for "death by hunger" (dbh).
        set gl-lte-eroi-dbh ( butfirst gl-lte-eroi-dbh )
        set gl-lte-eta-dbh  ( butfirst gl-lte-eta-dbh )
        set g-dbh-stat-count ( g-dbh-stat-count - 1 )
      ]
      set gl-lte-eroi-dbh ( lput lte-eroi gl-lte-eroi-dbh )
      set gl-lte-eta-dbh  ( lput lte-eta gl-lte-eta-dbh )
      set g-dbh-stat-count ( g-dbh-stat-count + 1 )
      set gl-lte-eroi-all
        ( sentence gl-lte-eroi-dbh gl-lte-eroi-dbo gl-lte-eroi-dbr )
      set gl-lte-eta-all
        ( sentence gl-lte-eta-dbh gl-lte-eta-dbo gl-lte-eta-dbr )
    ]

    ;; Record the lte-eroi and lte-eta data before death by old age.
    if( cause-of-death = ge-cod-oldage )
    [
      if( g-dbo-stat-count >= g-max-for-lte-stats )
      [
        ;; Remove old data for "death by old age" (dbo).
        set gl-lte-eroi-dbo ( butfirst gl-lte-eroi-dbo )
        set gl-lte-eta-dbo  ( butfirst gl-lte-eta-dbo )
        set g-dbo-stat-count ( g-dbo-stat-count - 1 )
      ]
      set gl-lte-eroi-dbo ( lput lte-eroi gl-lte-eroi-dbo )
      set gl-lte-eta-dbo  ( lput lte-eta gl-lte-eta-dbo )
      set g-dbo-stat-count ( g-dbo-stat-count + 1 )
      set gl-lte-eroi-all
        ( sentence gl-lte-eroi-dbh gl-lte-eroi-dbo gl-lte-eroi-dbr )
      set gl-lte-eta-all
        ( sentence gl-lte-eta-dbh gl-lte-eta-dbo gl-lte-eta-dbr )
    ]

    ;; Nrg was stripped out in do-move step.
    ;; However, nrg may exist for those who die of old age.
    f-increment-cod-list breed cause-of-death
    die  ;; The seeker disappears from the system.
  ]

  ;; End f-seeker-dies
end

;;-----------------------------------------------------------------------------|
;; D7 - do-post-tick procedure(s)
;;-----------------------------------------------------------------------------|

to do-post-tick
  ;; This routine is to be executed by the observer.

  if( gb-debug-on = 1 )
  [
    ifelse( ( gs-debug-step-chooser = "all" ) or ( gs-debug-step-chooser = "post-tick" ) )
    [ set gb-debug-flow-on 1  LOG-TO-FILE "" LOG-TO-FILE word "Do-Post-tick: Debug on; tick = " ticks ]
    [ set gb-debug-flow-on 0 ]
  ]

  ;; MANUAL CHANGE FOR DEBUG.
  ;; This is a call to a debug routine which could be suppressed if all is okay.
  ;; This is one of a group of such calls, most of which are between steps in
  ;;   the 'Go' routine.  They are suppressed there, but can be enabled again.
  ;; I have decided to leave this one active, for now.
  ;; It checks all agents, every tick, to ensure that all values are greater than
  ;;   or equal to zero.
  if( frb-agents-are-all-valid = false )
    [ LOG-TO-FILE ( word "  Do-post-tick: Agents failed validity test." ) ]

  ;; Global EROI system-wide calculations.
  set g-sys-nrg-returned
    ( sum gl-sys-nrg-returned ) ;; Total nrg returned within delta T (er).
  set g-sys-nrg-invested
    ( sum gl-sys-nrg-invested ) ;; Total nrg invested within delta T (ei).
  set g-sys-nrg-benefits
    ( g-sys-nrg-returned - g-sys-nrg-invested ) ;; (er-ei)

  ifelse( g-sys-nrg-invested > 0 )
    [ set g-sys-eroi ( g-sys-nrg-returned / g-sys-nrg-invested ) ] ;; (I/C)
    [ set g-sys-eroi 0 ] ;; (I/C)

  ifelse( g-sys-nrg-returned > 0 )
    [ set g-sys-eta ( g-sys-nrg-benefits / g-sys-nrg-returned ) ]  ;; (B/I)
    [ set g-sys-eta -5 ]  ;; (B/I)

  ;; Update the aggregates for display in the monitors.
  f-update-aggregates

  display

  LOG-TO-FILE "  Do-post-tick: procedure completed."
end

;;-----------------------------------------------------------------------------|
;; SECTION E – DRAWING AND MAINTENANCE PROCEDURE(S)
;;-----------------------------------------------------------------------------|

;;-----------------------------------------------------------------------------|
;; Update the values of global aggregate numbers.

to f-update-aggregates
  ;; This routine is to be executed by the observer.

  ;; Although this is a display-only routine, it may implicitly call the
  ;;   PRNG and so may have an effect on the trajectory of the model.  In a
  ;;   standard 'go' run it is called only once per tick, before graphs are
  ;;   updated.  If you use the one-step debug buttons, it is called once
  ;;   after each step, so debug runs that use those buttons will not
  ;;   replicate a real run.

  ;;---------------------------------------------------------------------------|
  ;; The following agent sets, counts and averages are for data collection
  ;;   and display in monitors and plots.

  ;; Counts
  ;; set g-no-of-patches ( count patches )
  set g-no-of-seekers ( count seekers )

  ;; Max value for eroi domain.
  let temp-list ( sentence gl-lte-eroi-dbh gl-lte-eta-dbr gl-lte-eroi-dbo)
  ifelse( ( length temp-list ) > 0 )
  [ set g-lte-eroi-max ( max temp-list) ]
  ;; else
  [ set g-lte-eroi-max ( 0 ) ]

  ;; Min value for eta domain.
  set temp-list ( sentence gl-lte-eta-dbh gl-lte-eta-dbr gl-lte-eta-dbo)
  ifelse( ( length temp-list ) > 0 )
  [ set g-lte-eta-min ( min temp-list ) ]
  ;; else
  [ set g-lte-eta-min ( 0 ) ]

  ;; Other histogram limits
  set g-hist-epm-max ( ( ceiling ( (  .1 + max [epm] of seekers ) * 10 ) ) / 10 )
  set g-hist-epm-min ( ( floor   ( ( -.1 + min [epm] of seekers ) * 10 ) ) / 10 )
  set g-hist-epa-max ( ceiling ( 1 + max [epa] of seekers ) )
  set g-hist-epa-min ( floor  ( -1 + min [epa] of seekers ) )

  ;; Averages - seekers
  ifelse( 0 = ( count seekers ) )
  [
    set g-ave-age      0        ;; age of seekers
    set g-ave-nrg      0        ;; nrg of seekers
    set g-ind-min-eroi 0        ;; eroi of seekers
    set g-ind-ave-eroi 0        ;; eroi of seekers
    set g-ind-max-eroi 0        ;; eroi of seekers
    set g-ind-min-eta  0        ;; eta of seekers
    set g-ind-ave-eta  0        ;; eta of seekers
    set g-ind-max-eta  0        ;; eta of seekers

    set g-ave-C1-b0   0         ;; c1, base character, gene-0
    set g-ave-C1-b1   0         ;; c1, base character, gene-1
    set g-ave-C1-b2   0         ;; c1, base character, gene-2
    set g-ave-C1-b3   0         ;; c1, base character, gene-3
    set g-ave-C1-b4   0         ;; c1, base character, gene-4
    set g-ave-C1-b5   0         ;; c1, base character, gene-5
    set g-ave-C1-b6   0         ;; c1, base character, gene-6
    set g-ave-C1-b7   0         ;; c1, base character, gene-7

    set g-ave-c1-e0   0         ;; c1, exponent character, gene-0
    set g-ave-c1-e1   0         ;; c1, exponent character, gene-1
    set g-ave-c1-e2   0         ;; c1, exponent character, gene-2
    set g-ave-c1-e3   0         ;; c1, exponent character, gene-3
    set g-ave-c1-e4   0         ;; c1, exponent character, gene-4
    set g-ave-c1-e5   0         ;; c1, exponent character, gene-5
    set g-ave-c1-e6   0         ;; c1, exponent character, gene-6
    set g-ave-c1-e7   0         ;; c1, exponent character, gene-7

    set g-ave-C1-s0   0         ;; c1, strength character, gene-0
    set g-ave-C1-s1   0         ;; c1, strength character, gene-1
    set g-ave-C1-s2   0         ;; c1, strength character, gene-2
    set g-ave-C1-s3   0         ;; c1, strength character, gene-3
    set g-ave-C1-s4   0         ;; c1, strength character, gene-4
    set g-ave-C1-s5   0         ;; c1, strength character, gene-5
    set g-ave-C1-s6   0         ;; c1, strength character, gene-6
    set g-ave-C1-s7   0         ;; c1, strength character, gene-7

    set g-ave-C1-p0   0         ;; c1, phenotypic character, gene-0
    set g-ave-C1-p1   0         ;; c1, phenotypic character, gene-1
    set g-ave-C1-p2   0         ;; c1, phenotypic character, gene-2
    set g-ave-C1-p3   0         ;; c1, phenotypic character, gene-3
    set g-ave-C1-p4   0         ;; c1, phenotypic character, gene-4
    set g-ave-C1-p5   0         ;; c1, phenotypic character, gene-5
    set g-ave-C1-p6   0         ;; c1, phenotypic character, gene-6
    set g-ave-C1-p7   0         ;; c1, phenotypic character, gene-7
  ]
  ;; Else
  [
    set g-ave-age       ( mean [age] of seekers )
    set g-ave-nrg       ( mean [nrg] of seekers )
    set g-ind-min-eroi  ( min  [ind-eroi] of seekers )
    set g-ind-ave-eroi  ( mean [ind-eroi] of seekers )
    set g-ind-max-eroi  ( max  [ind-eroi] of seekers )
    set g-ind-min-eta   ( min  [ind-eta] of seekers )
    set g-ind-ave-eta   ( mean [ind-eta] of seekers )
    set g-ind-max-eta   ( max  [ind-eta] of seekers )

    set g-ave-C1-b0 ( f-compute-C1-bases-average 0 )
    set g-ave-C1-b1 ( f-compute-C1-bases-average 1 )
    set g-ave-C1-b2 ( f-compute-C1-bases-average 2 )
    set g-ave-C1-b3 ( f-compute-C1-bases-average 3 )
    set g-ave-C1-b4 ( f-compute-C1-bases-average 4 )
    set g-ave-C1-b5 ( f-compute-C1-bases-average 5 )
    set g-ave-C1-b6 ( f-compute-C1-bases-average 6 )
    set g-ave-C1-b7 ( f-compute-C1-bases-average 7 )

    set g-ave-c1-e0 ( f-compute-c1-expos-average 0 )
    set g-ave-c1-e1 ( f-compute-c1-expos-average 1 )
    set g-ave-c1-e2 ( f-compute-c1-expos-average 2 )
    set g-ave-c1-e3 ( f-compute-c1-expos-average 3 )
    set g-ave-c1-e4 ( f-compute-c1-expos-average 4 )
    set g-ave-c1-e5 ( f-compute-c1-expos-average 5 )
    set g-ave-c1-e6 ( f-compute-c1-expos-average 6 )
    set g-ave-c1-e7 ( f-compute-c1-expos-average 7 )

    set g-ave-C1-s0 ( f-compute-c1-stren-average 0 )
    set g-ave-C1-s1 ( f-compute-c1-stren-average 1 )
    set g-ave-C1-s2 ( f-compute-c1-stren-average 2 )
    set g-ave-C1-s3 ( f-compute-c1-stren-average 3 )
    set g-ave-C1-s4 ( f-compute-c1-stren-average 4 )
    set g-ave-C1-s5 ( f-compute-c1-stren-average 5 )
    set g-ave-C1-s6 ( f-compute-c1-stren-average 6 )
    set g-ave-C1-s7 ( f-compute-c1-stren-average 7 )

    set g-ave-C1-p0 ( f-compute-c1-pheno-average 0 )
    set g-ave-C1-p1 ( f-compute-c1-pheno-average 1 )
    set g-ave-C1-p2 ( f-compute-c1-pheno-average 2 )
    set g-ave-C1-p3 ( f-compute-c1-pheno-average 3 )
    set g-ave-C1-p4 ( f-compute-c1-pheno-average 4 )
    set g-ave-C1-p5 ( f-compute-c1-pheno-average 5 )
    set g-ave-C1-p6 ( f-compute-c1-pheno-average 6 )
    set g-ave-C1-p7 ( f-compute-c1-pheno-average 7 )

  ]
  ;; End else

  ;; Calculate the entropic index of the energy distribution.
  set g-energy-entropic-index
    ( fr-get-energy-entropic-index ( [nrg] of seekers ) )
  print ""

  ;; Calculate the entropic index of the phenotype probability distribution.
  let l-pheno-partition ( fr-make-pheno-partition )
  set g-pheno-entropic-index ( fr-calc-pheno-entropic-index l-pheno-partition )

  ;; This log entry may come from any step during debug operations.
  LOG-TO-FILE "  Do-update: All aggregates updated."

  ;; End of f-update-aggregates
end

;;-----------------------------------------------------------------------------|
;; Clear the Life-Time Efficiency (LTE) data.

to f-clear-lte-data
  ;; This routine is to be executed by the observer.

  ;; Global lists for EROI/ETA for death by repro/hunger.
  set g-dbr-stat-count        0 ;; Count of ticks included in lists.
  set g-dbh-stat-count        0 ;; Count of ticks included in lists.
  set g-dbo-stat-count        0 ;; Count of ticks included in lists.
  ;; set g-max-for-lte-stats  0 ;; Maximum agents included [40,40,1000,1000]
  set gl-lte-eroi-dbr        [] ;; List of EROI for death by repro
  set gl-lte-eroi-dbh        [] ;; List of EROI for death by hunger
  set gl-lte-eroi-dbo        [] ;; List of EROI for death by old age
  set gl-lte-eroi-all        [] ;; List of EROI for death by all causes
  set gl-lte-eta-dbr         [] ;; List of ETA for death by repro
  set gl-lte-eta-dbh         [] ;; List of ETA for death by hunger
  set gl-lte-eta-dbo         [] ;; List of ETA for death by old age
  set gl-lte-eta-all         [] ;; List of ETA for death by all causes
  set g-lte-eroi-max          1 ;; Used to set max value for histograms

  ;; End of f-clear-lte-data
end

;;-----------------------------------------------------------------------------|
;; Compute an average for C1-bases, by preferred gene type.

to-report f-compute-C1-bases-average [ gene-to-check ]
  ;; This routine is to be executed by the observer.
  let count-of-seekers ( count seekers )
  let appropriate-sum ( sum ( [item gene-to-check c1-bases] of seekers ) )
  let answer 0
  if ( count-of-seekers > 0 )
    [ set answer ( appropriate-sum / count-of-seekers ) ]
  ;; LOG-TO-FILE ( word "  Do-update: g# - " gene-to-check ", ave [B] - " answer )

  report answer

  ;; End of f-compute-C1-bases-average
end

;;-----------------------------------------------------------------------------|
;; Compute an average for c1-expos, by preferred gene type.

to-report f-compute-c1-expos-average [ gene-to-check ]
  ;; This routine is to be executed by the observer.
  let count-of-seekers ( count seekers )
  let appropriate-sum ( sum ( [item gene-to-check c1-expos] of seekers ) )
  let answer 0
  if ( count-of-seekers > 0 )
    [ set answer ( appropriate-sum / count-of-seekers ) ]
  ;; LOG-TO-FILE ( word "  Do-update: g# - " gene-to-check ", ave [E] - " answer )

  report answer

  ;; End of f-compute-c1-expos-average
end

;;-----------------------------------------------------------------------------|
;; Compute an average for c1-stren, by preferred gene type.

to-report f-compute-c1-stren-average [ gene-to-check ]
  ;; This routine is to be executed by the observer.
  let count-of-seekers ( count seekers )
  let appropriate-sum ( sum ( [item gene-to-check c1-stren] of seekers ) )
  let answer 0
  if ( count-of-seekers > 0 )
    [ set answer ( appropriate-sum / count-of-seekers ) ]
  ;; LOG-TO-FILE ( word "  Do-update: g# - " gene-to-check ", ave [S] - " answer )

  report answer

  ;; End of f-compute-c1-stren-average
end

;;-----------------------------------------------------------------------------|
;; Compute an average for c1-pheno, by preferred gene type.

to-report f-compute-c1-pheno-average [ gene-to-check ]
  ;; This routine is to be executed by the observer.
  let count-of-seekers ( count seekers )
  let appropriate-sum ( sum ( [item gene-to-check c1-pheno] of seekers ) )
  let answer 0
  if ( count-of-seekers > 0 )
    [ set answer ( appropriate-sum / count-of-seekers ) ]
  ;; LOG-TO-FILE ( word "  Do-update: g# - " gene-to-check ", ave [P] - " answer )

  report answer

  ;; End of f-compute-c1-pheno-average
end

;;--------------------------
;; DATA CAPTURE TO CSV FILES
;;--------------------------

;;-----------------------------------------------------------------------------|
;; Record the data is several selected plots to CSV files

to f-record-selected-plots
  ;; This routine is to be executed by the observer.

  ;; The template for the export command is:
  ;; export-plot plotname filename

  ;; Get a common timestamp for all plots.
  let timestamp fr-get-time-stamp

  ;; Plot 01
  let plotname "[B]ase Values By Gene #"
  let plot-filename
    ( word timestamp
           "_Sc" g-scenario-number
           "_Se" g-use-this-seed
           "_Pl01_BVBG.CSV" )
  export-plot plotname plot-filename

  ;; Plot 02
  set plotname "[E]xponent Values By Gene #"
  set plot-filename
    ( word timestamp
           "_Sc" g-scenario-number
           "_Se" g-use-this-seed
           "_Pl02_EVBG.CSV" )
  export-plot plotname plot-filename

  ;; Plot 03
  set plotname "[S]trengths By Gene #"
  set plot-filename
    ( word timestamp
           "_Sc" g-scenario-number
           "_Se" g-use-this-seed
           "_Pl03_SVBG.CSV" )
  export-plot plotname plot-filename

  ;; Plot 04
  set plotname "[P]henotype Values By Gene #"
  set plot-filename
    ( word timestamp
           "_Sc" g-scenario-number
           "_Se" g-use-this-seed
           "_Pl04_PVBG.CSV" )
  export-plot plotname plot-filename

  ;; End f-record-selected-plots
end

;;-----------------------------------------------------------------------------|
;; Construct a time stamp for a file name for data in CSV format.

to-report fr-get-time-stamp
  ;; This routine is to be executed by the observer.
  ;;
  ;; Date-string format "01:19:36.685 PM 19-Sep-2002"
  let date-string date-and-time
  let time-stamp ""
  ;; Append the year as yy.
  set time-stamp word time-stamp ( substring date-string 25 27 )
  ;; Append the month as Mmm.
  set time-stamp word time-stamp fr-convert-mmm-mm ( substring date-string 19 22 )
  ;; Append the day as dd.
  set time-stamp word time-stamp ( substring date-string 16 18 )
  ;; Append a dash.
  set time-stamp word time-stamp "_"

  ;; Append the hour as hh.
  set time-stamp word time-stamp fr-convert1224 ( substring date-string 0 2 ) ( substring date-string 13 15 )
  ;; Append the minute as mm.
  set time-stamp word time-stamp ( substring date-string 3 5 )
  ;; Append the second as ss.
  set time-stamp word time-stamp ( substring date-string 6 8 )

  report time-stamp
  ;; End fr-get-time-stamp
end

;;-----------------------------------------------------------------------------|
;; DEBUG AND DEBUG LOG FILE MANAGEMENT FUNCTIONS
;;-----------------------------------------------------------------------------|

;;-----------------------------------------------------------------------------|
;; Open a log file for debug output.

to f-open-log-file
  ;; This routine is to be executed by the observer.

  ;; Ensure previous log file is closed.
  if ( is-string? gs-log-file-name )
  [
    if ( file-exists? gs-log-file-name )
    [
      file-close-all
    ]
  ]

  ;; Date-string format "01:19:36.685 PM 19-Sep-2002"
  let date-string date-and-time
  set gs-log-file-name "EffLab_I_Log_"
  ;; Append the year as yy.
  set gs-log-file-name word gs-log-file-name ( substring date-string 25 27 )
  ;; Append the month as Mmm.
  set gs-log-file-name word gs-log-file-name fr-convert-mmm-mm ( substring date-string 19 22 )
  ;; Append the day as dd.
  set gs-log-file-name word gs-log-file-name ( substring date-string 16 18 )
  ;; Append a dash.
  set gs-log-file-name word gs-log-file-name "_"

  ;; Append the hour as hh.
  set gs-log-file-name word gs-log-file-name fr-convert1224 ( substring date-string 0 2 ) ( substring date-string 13 15 )
  ;; Append the minute as mm.
  set gs-log-file-name word gs-log-file-name ( substring date-string 3 5 )
  ;; Append the second as ss.
  set gs-log-file-name word gs-log-file-name ( substring date-string 6 8 )
  ;; Append the .txt extension.
  set gs-log-file-name word gs-log-file-name ".txt"

  file-open gs-log-file-name
  file-show "Log File for a EffLab (NetLogo) Model."
  file-show word "File Name: " gs-log-file-name
  file-show word "File opened at:" date-and-time
  file-show ""

  ;; Send a message directly to the command centre.
  ifelse ( file-exists? gs-log-file-name )
  [
    show word gs-log-file-name " opened."
  ]
  [
    show word gs-log-file-name " not opened."
  ]
end

;;-----------------------------------------------------------------------------|
;; Convert month in text form to digital form.

to-report fr-convert-mmm-mm [ mmm ]
  ;; This routine is to be executed by the observer.
  ;; It converts a string in the form mmm ( alpha text ) to the form mm ( digit-text ).

  let mm "00"
  if( mmm = "Jan" ) [ set mm "01" ]
  if( mmm = "Feb" ) [ set mm "02" ]
  if( mmm = "Mar" ) [ set mm "03" ]
  if( mmm = "Apr" ) [ set mm "04" ]
  if( mmm = "May" ) [ set mm "05" ]
  if( mmm = "Jun" ) [ set mm "06" ]
  if( mmm = "Jul" ) [ set mm "07" ]
  if( mmm = "Aug" ) [ set mm "08" ]
  if( mmm = "SeP" ) [ set mm "09" ]
  if( mmm = "Oct" ) [ set mm "10" ]
  if( mmm = "Nov" ) [ set mm "11" ]
  if( mmm = "Dec" ) [ set mm "12" ]
  report mm
end

;;-----------------------------------------------------------------------------|
;; Convert hour in 12 format to 24 hour format.

to-report fr-convert1224 [ hh ampm ]
  ;; This routine is to be executed by the observer.
  ;; It converts a string in 12 hour format to 24 hour format.

  let hour read-from-string hh
  if( ampm = "PM" ) [ set hour ( hour + 12 ) ]

  let dd ( word "00" hour )
  let d2 last dd
  set dd but-last dd
  let d1 last dd
  set dd ( word d1 d2 )
  report dd
end

;;-----------------------------------------------------------------------------|
;; Close a log file for debug output.

to f-close-log-file
  ;; This routine is to be executed by the observer.

  let b-filename-exists 0
  if ( is-string? gs-log-file-name )
  [
    if ( file-exists? gs-log-file-name )
    [
      set b-filename-exists 1
    ]
  ]

  ifelse( b-filename-exists = 1 )
  [
    ;; Ensure the file is selected.
    file-open gs-log-file-name

    ;; Stanp it.
    LOG-TO-FILE word "File closed at: " date-and-time

    ;; Flush the buffers.
    file-flush

    ;; Close it.
    file-close-all

    ;; Note sent to command centre.
    show word gs-log-file-name " closed."

    ;; Revert to dummy name.
    set gs-log-file-name "dummyname"
  ]
  [
    if( gs-log-file-name = "dummyname" )
      [ show "No log file is open.  Cannot close it." ]
  ]
end

;;-----------------------------------------------------------------------------|
;; Select an already opened log file.

to f-select-log-file
  ;; This routine is to be executed by the observer.

  ifelse ( file-exists? gs-log-file-name )
  [
    ;; Ensure the file is selected.
    file-open gs-log-file-name

    ;; Ensure it is open for writing.
    LOG-TO-FILE ""
    LOG-TO-FILE "SELECTED"
  ]
  [
    show word gs-log-file-name " is not open.  Cannot select it."
  ]
end

;;-----------------------------------------------------------------------------|
;; Change the debug mode from on to off, or vice versa.

to f-toggle-debug
  ;; This routine is to be executed by the observer, and is activated by a
  ;;   button.

  ifelse( gb-debug-on = 1 )
  [
    ;; Debug is On, turn it Off.
    ;; Close the file before turning debug logging off.
    f-close-log-file
    set gs-debug-status "0 (Off)"  ;; This appears in the monitor.
    set gb-debug-on 0              ;; But this controls the debug feature.
  ]
  [
    ;; Debug is Off, turn it On.
    set gs-debug-status "1 (On)"   ;; This appears in the monitor.
    set gb-debug-on 1              ;; But this controls the debug feature.
    ;; The switches, if needed, are reset manually by the user.
    ;; Open the log file after turning debug logging on.
    f-open-log-file
  ]
end

;;-----------------------------------------------------------------------------|
;; 'Show' a string in a debug log.

to LOG-TO-FILE [ log-this-string ]
  ;; This routine may be executed by observer or seeker.
  ;; It should be invoked as a debug routine only, and would not be used for
  ;;    normal output.  It sends output to the debug log file, or, optionally,
  ;;    also to the command centre.

  ;; gb-debug-on is a global Boolean and has value 1 (true) or 0 (false).
  if( gb-debug-on = 1 )
  [
    ;; gb-debug-flow-on is declared as a global Boolean variable, and its value
    ;;   is 0 ( false ) or 1 ( true ) and is set on or off at the beginning of each
    ;;   function ( each do-step ).  It is controlled by the chooser that selects 'all'
    ;;   or a specific do-function.
    ;;
    ;; When it is 'on' you can assume the debug log file exists and is open for
    ;;   write.

    if( gb-debug-flow-on = 1 )
    [
      file-show log-this-string
      show log-this-string
    ]
  ]
end

;;-----------------------------------------------------------------------------|
;; This replicates the effect of an 'ASSERTION' in C++

to ASSERT [ error-test error-string error-who ]
;; This routine can be run by observer or seeker.

if( error-test = false )
[
  show ( word error-test " " error-string " " error-who )
  ;; Cause a run-time error and display a message.
  error ( word "Agent: " error-who " - " error-string )
]
end

;;-----------------------------------------------------------------------------|
;; Check whether the nrg accounts are all valid.

to-report frb-nrg-accounts-are-all-valid
;; This routine can be run by the observer.

  let b-accounts-are-all-valid 1

  if( gb-debug-on = 1 )
  [
    ;; Do the check only if debug is on.
    let temp-nrg-in-seekers  ( sum [nrg] of seekers )
    let temp-nrg-in-fruit    ( sum [fruit] of patches )

    let temp-total-nrg ( temp-nrg-in-seekers +
      temp-nrg-in-fruit )

    if (temp-nrg-in-fruit != g-nrg-in-fruit )
    [
      set b-accounts-are-all-valid 0
      LOG-TO-FILE ( word
        "F-nrg-check: SB:" temp-nrg-in-fruit
        ", IS:" g-nrg-in-fruit )
    ]

    if (temp-nrg-in-seekers != g-nrg-in-agents )
    [
      set b-accounts-are-all-valid 0
      LOG-TO-FILE ( word
        "S-nrg-check: SB:" temp-nrg-in-seekers
        ", IS:" g-nrg-in-agents )
    ]

    if (temp-total-nrg != g-nrg-in-system )
    [
      set b-accounts-are-all-valid 0
      LOG-TO-FILE ( word
        "T-nrg-check: SB:" temp-total-nrg
        ", IS:" g-nrg-in-system )
    ]
  ]

  report b-accounts-are-all-valid

  ;; End of frb-nrg-accounts-are-all-valid
end

;;-----------------------------------------------------------------------------|
;; Check whether the agents are all valid.

to-report frb-agents-are-all-valid
;; This routine can be run by the observer.

  let b-agents-are-all-valid true

  if( gb-debug-on = 1 )
  [
    ;; Do the check only if debug is on.

    ;; Check the seekers.
    ask seekers
    [
      if( frb-seeker-is-valid = false ) [ set b-agents-are-all-valid false ]
    ]
  ]

  report b-agents-are-all-valid

  ;; End of frb-agents-are-all-valid
end

;;-----------------------------------------------------------------------------|
;; Check whether a seeker is valid.

to-report frb-seeker-is-valid
;; This routine can be run by a seeker.

  let b-seeker-is-valid true

  report b-seeker-is-valid

  ;; End of frb-seeker-is-valid
end

;;---------------------------------------------------------------------|-------|
;;  Partitions in ABMs.  Entropic index in ABMs.  GammaLn() function in ABMs.
;;---------------------------------------------------------------------|-------|
;;
;; REFERENCES: The diary notes including (or more recent versions):
;; A.  150527 PPR - Definition of Ei R17.PDF
;; B.  190927 NTF Shannon Vs Boltzmann R4.PDF
;; C.  180214 NTF Entropy and Units of Measure R5.PDF
;; D.  180822 NTF FactLn() and GammaLn() R3.PDF
;; E.  190927 NTF Entropy in a Histogram R4.PDF
;;

;; NOTE:  These routines create a partition (i.e. a histogram) independent of
;;   the capabilities of the plot controls in the interface tab.

;;---------------------------------------------------------------------|-------|

to-report fr-get-energy-entropic-index [ l-data-input ]
  ;; This routine is to be executed by the observer.

  ;; show "----------"
  ;; show "fr-get-energy-entropic-index"

  let l-energy-partition ( fr-make-energy-partition l-data-input )
  ;; show ( word "fr-nrg-ei: l-energy-partition - " l-energy-partition )

  let nrg-ei ( fr-calc-energy-entropic-index l-energy-partition )
  ;; show ( word "nrg-ei: " nrg-ei )

  report nrg-ei

  ;; End of fr-get-energy-entropic-index
end

;;---------------------------------------------------------------------|-------|

to-report fr-make-energy-partition [ l-data-input ]
  ;; This routine is to be executed by the observer.

  ;; show "----------"
  ;; show "fr-make-energy-partition"
  ;; show ( word "l-data-input:" l-data-input )

  ;; It creates binned data (a partition) that can be used to plot a histogram.
  ;; A typical call might look like this:
  ;;  set l-energy-partition
  ;;              ( fr-make-energy-partition ( [energy] in seekers ) )
  ;;  reports [ l-partition ]

  ;; Allocate memory.
  let a-no-of-agents length l-data-input
  let k-no-of-bins ( floor ( sqrt a-no-of-agents ) )
  let ave-data ( mean l-data-input )
  let min-data ( ( min l-data-input ) - 0.001 )
  let max-data ( ( max l-data-input ) + 0.001 )
  let bin-delta 0
    ;; show ( word "fmep: ave-data(1): " ave-data )
    ;; show ( word "fmep: min-data(1): " min-data )
    ;; show ( word "fmep: max-data(1): " max-data )
    ;; show ( word "fmep: bin-delta(1): " bin-delta )
    ;; show ""

  ifelse ( ( max-data - min-data ) < k-no-of-bins )
  [
    ;; Case of all data-points being the same.
    set min-data ( ave-data - ( k-no-of-bins / 2 ) )
    set max-data ( ave-data + ( k-no-of-bins / 2 ) )
    set bin-delta ( ( max-data - min-data ) / k-no-of-bins )
    ;; show ( word "fmep: min-data(2): " min-data )
    ;; show ( word "fmep: max-data(2): " max-data )
    ;; show ( word "fmep: bin-delta(2): " bin-delta )
  ]
  ;; Else
  [
    set bin-delta ( ( max-data - min-data ) / k-no-of-bins )
  ]

  ;; Initialize the output histogram with zeros.
  let l-partition ( n-values k-no-of-bins [0] )
  ;; show ( word "fmep: l-partition: " l-partition )

  let counter 0
  let data-point 0
  let bin-no 0
  let agents-in-bin 0
  let limit ( ( length l-data-input ) - 1 )
  ;; show ( word "fmep: limit: " limit )

  while [counter <= limit ]
  [
    ;; show ( word "fmep: counter(3): " counter )
    set data-point ( item counter l-data-input )
    ;; We need to convert this data point into a bin-number for the partition.
    set bin-no ( ( ( data-point - min-data ) / bin-delta ) )
    ;; show ( word "fmep: bin-no(3): " bin-no )
    set bin-no ( floor ( ( data-point - min-data ) / bin-delta ) )
    ;; show ( word "fmep: bin-no(3): " bin-no )
    ;; bin-no is a whole number which determines which bin the agent is counted in.
    ;; show ( word "fmep: data-point(3): " data-point )
    ;; show ( word "fmep: min-data(3): " min-data )
    ;; show ( word "fmep: bin-delta(3): " bin-delta )

    set agents-in-bin ( item bin-no l-partition )
    set agents-in-bin ( agents-in-bin + 1 )
    set l-partition ( replace-item bin-no l-partition agents-in-bin )

    set counter ( counter + 1 )
  ]

  report l-partition

  ;; End fr-make-energy-partition.
end

;;---------------------------------------------------------------------|-------|

to-report fr-calc-energy-entropic-index [ l-partition ]
  ;; This routine can be called by any agent.

  ;; show "----------"
  ;; show "fr-calc-energy-entropic-index"

  ;; It uses the formula that was developed in a series of diary notes
  ;;   that investigated the most effective formula for calculating
  ;;   entropy in an agent-based model such as "Model I" of EiLab.

  ;; I hypothesize that it is equally valid in most agent-based models, but
  ;;   that hypothesis needs to be expored and examined and tested.

  ;; THIS IS AN EXAMPLE OF AN AS-YET UNEXAMINED USAGE.

  ;;
  ;; REFERENCES: The diary notes including (or more recent versions):
  ;; A.  150527 PPR - Definition of Ei R17.PDF
  ;; B.  190927 NTF Shannon Vs Boltzmann R4.PDF
  ;; C.  180214 NTF Entropy and Units of Measure R5.PDF
  ;; D.  180822 NTF FactLn() and GammaLn() R3.PDF
  ;; E.  190927 NTF Entropy in a Histogram R4.PDF
  ;;

  ;; The formula used is equation 30 in the Ref E document.

  ;; It can be written like this:
  ;;   I = (GammaLn(A+1) - Sum(GammaLn(ai+1))) / (A*Ln(K))
  ;;   where:
  ;;          K is the number of bins in a histogram of some conserved quantity.
  ;;          A is the number of agents in the model.
  ;;          ai is the count of agents in bin i of the histogram.

  ;; The expected input is a partition constructed from a list of energy values.
  ;; The sum of all elements of all bins equals the number of agents.
  let a-no-of-agents ( sum l-partition )
  let k-no-of-bins ( length l-partition )

  ;; Note that GammaLn( ) is not native to NetLogo.  A version is implemented
  ;;   below.

  ;; show ( word "l-partition: " l-partition )

  let entropic-index fr-gammaln ( 1 + a-no-of-agents )
  foreach l-partition
     [ set entropic-index ( entropic-index - fr-gammaln ( 1 + ? ) ) ]

  let alpha ( a-no-of-agents / k-no-of-bins )
  let boltzmann-max ( fr-gammaln ( 1 + a-no-of-agents ) )
  set boltzmann-max
    ( boltzmann-max - ( k-no-of-bins * fr-gammaln ( alpha + 1 ) ) )

  set entropic-index ( entropic-index / boltzmann-max )

  report entropic-index

  ;; End of fr-calc-entropic-index.
end

;;---------------------------------------------------------------------|-------|

to-report fr-make-pheno-partition
  ;; This routine is to be executed by the observer.

  ;; show "----------"
  ;; show "fr-make-pheno-partition"

  ;; It creates binned data (a partition) that can be used to plot a histogram.
  ;; A typical call might look like this:
  ;;  set l-pheno-partition ( fr-make-pheno-partition )
  ;;  reports [ l-partition ]

  ;; Allocate memory.
  let a-no-of-agents count turtles
  let k-no-of-bins 8
  let new-value 0
  let l-pheno-list 0

  ;; Initialize the output histogram with zeros.
  let l-partition ( n-values k-no-of-bins [0] )
  ;; show ( word "fmpp: l-partition: " l-partition )

  ;; One-by-one, calculate the average phenotype value, and insert.
  let counter 0
  let limit ( length l-partition )
  while [ counter < limit ]
  [
    set l-pheno-list ( [ item counter c1-pheno ] of seekers )
    ;; show ( word "fmpp: l-pheno-list: " l-pheno-list )
    set new-value ( mean l-pheno-list )
    ;; show ( word "fmpp: new-value: " new-value )
    set l-partition ( replace-item counter l-partition new-value )
    ;; show ( word "fmpp: l-partition:" l-partition )
    set counter ( counter + 1 )
  ]

  ;; show ( word "fmpp: l-partition: " l-partition )
  set gl-ave-pheno l-partition

  report l-partition

  ;; End fr-make-pheno-partition.
end

;;---------------------------------------------------------------------|-------|

to-report fr-calc-pheno-entropic-index [ l-partition ]
  ;; This routine can be called by any agent.

  ;; show "----------"
  ;; show "fr-calc-pheno-entropic-index"

  ;; It uses the formula that was developed in a series of diary notes
  ;;   that investigated the most effective formula for calculating
  ;;   entropy in an agent-based model such as "Model I" of EiLab.

  ;; I hypothesize that it is equally valid in most agent-based models, but
  ;;   that hypothesis needs to be expored and examined and tested.

  ;; THIS IS AN EXAMPLE OF AN AS-YET UNEXAMINED USAGE.

  ;;
  ;; REFERENCES: The diary notes including (or more recent versions):
  ;; A.  150527 PPR - Definition of Ei R17.PDF
  ;; B.  190927 NTF Shannon Vs Boltzmann R4.PDF
  ;; C.  180214 NTF Entropy and Units of Measure R5.PDF
  ;; D.  180822 NTF FactLn() and GammaLn() R3.PDF
  ;; E.  190927 NTF Entropy in a Histogram R4.PDF
  ;;

  ;; The formula used is equation 30 in the Ref E document.

  ;; It can be written like this:
  ;;   I = (GammaLn(A+1) - Sum(GammaLn(ai+1))) / (A*Ln(K))
  ;;   where:
  ;;          K is the number of bins in a histogram of some conserved quantity.
  ;;          A is the number of agents in the model.
  ;;          ai is the count of agents in bin i of the histogram.

  ;; The expected input is a partition constructed from a list of energy values.
  ;; The sum of all elements of all bins equals the number of agents.
  let a-total ( sum l-partition )
  let k-no-of-bins ( length l-partition )

  ;; Note that GammaLn( ) is not native to NetLogo.  A version is implemented
  ;;   below.

  ;; show ( word "frcpei: l-partition: " l-partition )

  let entropic-index fr-gammaln ( 1 + a-total )
  foreach l-partition
     [ set entropic-index ( entropic-index - fr-gammaln ( 1 + ? ) ) ]

  let alpha ( a-total / k-no-of-bins )
  let boltzmann-max ( fr-gammaln ( 1 + a-total ) )
  set boltzmann-max
    ( boltzmann-max - ( k-no-of-bins * fr-gammaln ( alpha + 1 ) ) )

  set entropic-index ( entropic-index / boltzmann-max )

  report entropic-index

  ;; End of fr-calc-pheno-entropic-index.
end

;;---------------------------------------------------------------------|-------|

to-report fr-gammaln [ input-value ]
  ;; This routine can be called by any agent.

  ;; It reproduces a routine found on page 207 of this book:
  ;; Press, Teukolsky, Vetterling and Flanery (1986) "Numerical Recipes in
  ;;   Fortran", Cambridge, pp 206-209.
  ;; It uses Lanczos' approximation of the Ln(Gamma(x)) function.
  ;; Note that, when input-value is an integer, GammaLn(x+1) approximates Ln(x!).
  ;; When x = 160, the error seems to be about 1 in a billion.  That's pretty good.

  ;; This follows the Fortran code rather closely here.
  let x input-value
  let y x
  let tmp ( x + 5.5 )
  ;; Note that here I use ln( ) instead of log( ) as shown in the text.
  ;; The same problem comes up down below also.  With ln() it seems
  ;;   to work correctly.
  set tmp ( ( ( x + 0.5 ) * ( ln tmp ) ) - tmp )
  let ser 1.000000000190015

  ;; Next, I have unscrolled the six iterations of the loop.
  ;; cof(6) is now six different parameters.

  ;; Iteration 1
  set y ( y + 1 )
  set ser ( ser + ( 76.18009172947146 / y ) )

  ;; Iteration 2
  set y ( y + 1 )
  set ser ( ser + ( -86.50532032941677 / y ) )

  ;; Iteration 3
  set y ( y + 1 )
  set ser ( ser + ( 24.01409824083091 / y ) )

  ;; Iteration 4
  set y ( y + 1 )
  set ser ( ser + ( -1.231739572450155 / y ) )

  ;; Iteration 5
  set y ( y + 1 )
  set ser ( ser + ( 0.001208650973866179 / y ) )

  ;; Iteration 6
  set y ( y + 1 )
  set ser ( ser + ( -0.000005395239384953 / y ) )

  ;; Now, I follow the Fortran code closely again.
  let stp 2.5066282746310005

  ;; Note that here I use ln( ) instead of log( ) as shown in the text.
  let gammaln ( tmp + ( ln ( stp * ser / x ) ) )

  report precision gammaln 15

  ;; End of fr-gammaln.
end

;;---------------------------------------------------------------------|-------|

to-report fr-factorial [ input-value ]
  ;; This routine can be called by any agent.

  ;; It uses recursion to calculate n!.
  let n input-value
  ifelse ( n > 0 ) [ report n * fr-factorial ( n - 1 ) ]
                   [ report 1 ]

  ;; End of fr-factorial.
end

;;---------------------------------------------------------------------|-------|

to-report fr-factorialln [ input-value ]
  ;; This routine can be called by any agent.

  ;; It uses the recursive function to calculate n!, then takes the logarithm.
  let n input-value
  let factorialln fr-factorial n

  report precision ( ln factorialln ) 15

  ;; End of fr-factorialln.
end
