Coral Reef Simulation

; set up the agents
breed [ clams clam ]
breed [ pfishes pfish ]
breed [ larvae larva ]
breed [ butterflyfishes butterflyfish ]
breed [ sharks shark ]

turtles-own [ energy ] ; all agent will have a parameter energy

patches-own [ coral-growth neighbor-factor ind-growth-rate ]

globals [
  clam-energy-max
  bfish-energy-max
  pfish-energy-max
  shark-energy-max
  coral-maturity-size
  dynamite-fishing-event-tick
]

to setup
  clear-all
  clear-output

  print "Let's simulate a small reef !"

  ; globals parameters definition
  set clam-energy-max 100
  set bfish-energy-max 150
  set pfish-energy-max 500
  set shark-energy-max 1000
  set coral-maturity-size 100
  set dynamite-fishing-event-tick random time-before-explosion

  ; environment definition
  setup-background
  setup-coral-blobs
  setup-larvae
  setup-planktivore
  setup-pfishes

  reset-ticks
end

to go
  ; stopping conditions:
  if ticks > 10000 [user-message "10,000 ticks reached" stop]
  if all? patches [pcolor = 49] [user-message "All the coral is dead, it's the end of the world !"]

  if (count pfishes + count butterflyfishes) >= ecosystem-capacity and count sharks = 0 [
    setup-sharks
  print "All these fishes have attracted sharks !"]

  ask larvae [
    move-larvae
    set energy energy - random-float 1 ; at each step, deduct 1 point of energy
    if random-float 1 < 0.1 [
      settle ]
    death
  ]

  ask pfishes [
    move-pfishes
    set energy energy - random 5 ; at each step, deduct 5 points of energy because a fish need more energy to swim
    if energy <= pfish-energy-max and random-float 1 < 0.3 [
      eat-coral ]
    reproduce-pfish
    death
  ]

  if count pfishes <= 1 [
    if random-float 1 < 0.001 [
      create-pfishes 1 [
        setxy random-xcor random-ycor
        set shape "parrot fish"
        set color cyan
        set size 15
        set energy random (parrotfish-energy / 2) + (parrotfish-energy / 2)
      ]
      print "A parrot fish has been attracted."
    ]
  ]

  ask sharks [
    move-shark
    set energy energy - 20
    if energy <= shark-energy-max and random-float 1 < 0.5 [
      eat-fish]
    death
  ]

  ask patches  with [pcolor = orange or pcolor = 116 or pcolor = green] [
    grow
    if random-float 1 < 0.0005 [
      seed-new-coral self]
    ; check maturity
    if coral-growth < 0 [ set coral-growth 0 ] ; cannot be negative
    if coral-growth > 0 and coral-growth <= 100 [
      set pcolor orange ]
    if coral-growth >= coral-maturity-size [
      set pcolor 116 ] ; mature coral turns purple
    if coral-growth = 0 [
      set pcolor 49
      set ind-growth-rate  0
    ]
    hatch-larvae_
  ]

  if Planktivores [

    ask butterflyfishes[
      if energy <= bfish-energy-max and random-float 1 < 0.3 [
        butterflyfish-eats-larvae ]
      move-bfishes
      set energy energy - ( random 2 ) ; smaller than a parrot fish thus movement costs less energy
      reproduce-bfish
      death
    ]
    ask clams [
      if energy <= clam-energy-max and random-float 1 < 0.8 [
        clam-eats-larvae ]
      set energy energy - (random-float 1 )
      reproduce-clam
      death
    ]

  if Planktivore-species = "butterflyfishes" or Planktivore-species = "both" [
      if (count butterflyfishes) <= 1 [
    if random-float 1 < 0.001 [
      create-butterflyfishes 1 [
        set shape "butterflyfish"
        set color green
        set size 15
        set energy random (bfish-energy-max / 2) + (bfish-energy-max / 2)
        setxy random-xcor random-ycor
        ]
          print "A butterflyfish has been attracted."
      ]
    ]
  ]
    if Planktivore-species = "clams" or Planktivore-species = "both" [
      if (count clams) = 0 [
    if random-float 1 < 0.001 [
      let eligible-patches patches with [ (pcolor = orange or pcolor = 116) and count neighbors with [pcolor = orange or pcolor = 116] >= 4 ]
        if any? eligible-patches [
        ask n-of 1 eligible-patches [
          sprout-clams 1 [
            set shape "giant clam"
            set color 107
            set size 18
            set energy random (clam-energy-max / 2) + (clam-energy-max / 2)]]
        ]
          print "A giant clam has just settled."
      ]

    ]
  ]
]

  ; Define the threats
  if Global-warming and (ticks mod 50 = 0) [ ; global-warming significantly decrease the growth rate but progressively
  ask patches with [pcolor = orange or pcolor = 116] [
    if random-float 1 < 0.2 [  ; 20% chance per patch every 50 ticks
      set ind-growth-rate ind-growth-rate * (1 - random-float 0.05 - 0.025)
      ; cap at a minimum value to prevent collapse
      if ind-growth-rate < 0.01 [
        set ind-growth-rate 0.01
      ]
    ]
  ]
]

  if Acidification [ ; acidification significantly decrease the size of coral (make it harder to reach maturity and then die) but progressively
  ask patches with [pcolor = orange or pcolor = 116] [
    if random-float 1 < 0.005 [
        set coral-growth coral-growth * (1 - random-float 0.05 )]
      if coral-growth < 0.01 [
        set coral-growth 0]
      ]
    ]

  if Dynamite-fishing and (ticks = dynamite-fishing-event-tick) [
  ; Destroy most of the grid
  ask patches [
    if random-float 1 < 0.5 [  ; 50% chance to destroy each patch
      set pcolor 49  ; sand
      set coral-growth 0
      set ind-growth-rate 0
    ]
  ]

  ; Kill all agents
  ask turtles [
    if random-float 1 < 0.7 [
        die
  ]
    ]
    user-message "Oh no! Your reef has been dynamited!"
    ; schedule next event
      set dynamite-fishing-event-tick ticks + round( random (time-before-explosion / 2 ) + (time-before-explosion / 2 ) )
    print (word "Next explosion at tick: " dynamite-fishing-event-tick)
  ]

  tick
end

to setup-background
  ; Set sandy background
  ask patches [ set pcolor 49]
end

to setup-coral-blobs
  repeat number-of-blobs [
    let cx random-xcor ;cx and cy for the center of the blob
    let cy random-ycor
    ask patches [
      let dx_ abs (pxcor - cx) ; dx_ and dy_ are the absolute value from the patch to the center of the current blob
      let dy_ abs (pycor - cy)
      let dist sqrt (dx_ * dx_ + dy_ * dy_) ; euclidean distance from the patch to the blob center
      let noise random-float 1.3 - 0.5 ; add randomness to the distance of the plot to make it more irregular and with a more "organic" shape
      let dist-fuzzed dist + noise ; apply the noise/randomness to the distance
      ; to pick an overall round shape
      let blob-size random (blob-radius / 2) + 2 * (blob-radius / 2)
      if dist-fuzzed <= blob-size [
        let edge-factor 1 - (dist-fuzzed / blob-size)
        if random-float 1 < (edge-factor ^ 1.2) [
         set coral-growth random (reef-age / 2) + (reef-age / 2)
          ifelse coral-growth = 0 [
            set pcolor 49]
          [ set pcolor orange]
         set ind-growth-rate random-float (coral-growth-rate / 2) + (coral-growth-rate / 2)
          if coral-growth >= coral-maturity-size [ set pcolor 116 ]
        ]
      ]
    ]
  ]
end

to setup-larvae
  create-larvae Nb-larvae
  [
    setxy random-xcor random-ycor
    set color gray
    set size 3
    set energy random ((larva-energy / 2)) + ((larva-energy / 2)) ; when a larvae is created its energy level take a random value between [Larva-energy/2 ; Larva-energy]
  ]
end

to setup-pfishes
  create-pfishes Nb-parrotfishes
  [
    setxy random-xcor random-ycor
    set shape "parrot fish"
    set color cyan
    set size 15
    set energy random (parrotfish-energy / 2) + (parrotfish-energy / 2)
  ]
end

to setup-planktivore
  if Planktivores [
    if Planktivore-species = "clams" [
      let eligible-patches patches with [ (pcolor = orange or pcolor = 116) and count neighbors with [pcolor = orange or pcolor = 116] >= 4 ]
        if any? eligible-patches [
        ask n-of Nb-clams eligible-patches [
          sprout-clams 1 [
            set shape "giant clam"
            set color 107
            set size 18
            set energy random (clam-energy-max / 2) + (clam-energy-max / 2)
          ]
        ]
      ]
    ]
    if Planktivore-species = "butterflyfishes" [
      create-butterflyfishes Nb-butterflyfishes [
        set shape "butterflyfish"
        set color green
        set size 15
        set energy random (bfish-energy-max / 2) + (bfish-energy-max / 2)
        setxy random-xcor random-ycor
      ]
    ]
    if Planktivore-species = "both" [
      let eligible-patches patches with [ (pcolor = orange or pcolor = 116) and count neighbors with [pcolor = orange or pcolor = 116] >= 4 ]
        if any? eligible-patches [
        ask n-of Nb-clams eligible-patches [
          sprout-clams 1 [
            set shape "giant clam"
            set color 107
            set size 18
            set energy random (clam-energy-max / 2) + (clam-energy-max / 2)]
        ]
      ]
      create-butterflyfishes Nb-butterflyfishes [
        set shape "butterflyfish"
        set color green
        set size 15
        setxy random-xcor random-ycor
        set energy random (bfish-energy-max / 2) + (bfish-energy-max / 2)
              ]
    ]
  ]
end

to setup-sharks
    create-sharks random Nb-sharks [
      set shape "shark"
      set color gray
      set size 30
      set energy random (shark-energy-max / 2) + (shark-energy-max / 2)
      setxy random-xcor random-ycor
    ]
 ; ]
end

to grow ; make the coral grow and adding a neighbor factor to mimic competition
    let neighbor-coral count neighbors with [pcolor = orange or pcolor = 116 or pcolor = green]
    ; calculate neighbor influence with competition
    set neighbor-factor 1 ; default value
    if member? neighbor-coral [1 2 3 ] [
      set neighbor-factor 1.05] ; when few neighbor the growth is boosted
    if member? neighbor-coral [4 5 6 7 8] [
        set neighbor-factor 0.8 ] ; when too many neighbor, the growth is slow down because of competition
    ; ensure neighbor-factor stays positive (so growth can't go negative)
    if neighbor-factor < 0 [ set neighbor-factor 0 ]
    ; apply growth
  ifelse ind-growth-rate = 0 [
    set coral-growth coral-growth ]
  [ if ind-growth-rate > 0
    [ set coral-growth coral-growth + (ind-growth-rate * neighbor-factor) ]
  ]
end

to seed-new-coral [origin]
  let target-patch one-of neighbors
  if target-patch != nobody [
    ask target-patch [
      ; if there is already coral, high chance (50 %) to have a growth boost
      ifelse pcolor = orange or pcolor = 116 or pcolor = green [
        if random-float 1 < 0.5 [
          set coral-growth coral-growth + random 5
      ]
      ]
      [ if pcolor = 49 [
         ; low probability (30%) to establish on sand
         if random-float 1 < 0.3  [
          set pcolor orange
          set coral-growth 0.1
          set ind-growth-rate random-float (coral-growth-rate / 2) + (coral-growth-rate / 2)
          ]
      ]
    ]
  ]
  ]
end

to hatch-larvae_
  if pcolor = 116 [
    ifelse Full-moon [
      if ticks mod 150 = 0 and random-float 1 < (spawning-frequency * 1.8) [
        sprout random (Nb-larvae-produced / 2) + (Nb-larvae-produced / 2) [
          set breed larvae
          set color grey
          set size 3
          set energy random (larva-energy / 2) + (larva-energy / 2)
          rt random 360
          fd 1
        ]
      ]
    ]
     [
      if random-float 1 < (spawning-frequency / 100) [
        sprout random (Nb-larvae-produced / 2) + (Nb-larvae-produced / 2) [
          set breed larvae
          set color grey
          set size 3
          set energy random (larva-energy / 2) + (larva-energy / 2)
          rt random 360
          fd 1
        ]
      ]
    ]
  ]
end

to move-larvae
    ; movement
    right random 360 ; turn a random number of degrees between 1 and 359
    forward 1 ; move forward 1 step
end

to settle
  ifelse pcolor = orange or pcolor = 116 [
    if random-float 1 < 0.05 [
      set ind-growth-rate ind-growth-rate + random-float 0.1
      set color orange
      die ; the larvae disappear after settlement
    ]
  ] [
    if pcolor = 49 [
      if random-float 1 < 0.3 [
        set pcolor orange
        set coral-growth 0.01
        set ind-growth-rate ind-growth-rate + (random-float (coral-growth-rate / 2) + (coral-growth-rate / 2))
        die
      ]
    ]
  ]
end

to move-pfishes
  ifelse random-float 1 < 0.1 [
    let nearby-coral patches in-radius 50 with [pcolor = orange or pcolor = 116]
    if any? nearby-coral [
      let target min-one-of nearby-coral [distance myself]
      face target
      fd 1 ] ; move toward coral
  ] [
    ; random movement
      rt random 50
      lt random 50
      fd 1 ] ; move forward 1 step
end

to move-bfishes
  ifelse random-float 1 < 0.1 [
    let nearby-larvae larvae in-radius 50
    if any? nearby-larvae [
      let target min-one-of nearby-larvae [distance myself]
      face target
      fd 1 ] ; move toward larvae
  ] [
    ; random movement
      rt random 50
      lt random 50
      fd 1 ] ; move forward 1 step
end

to move-shark
  ifelse random-float 1 < 0.3 [
    let nearby-fish turtles in-radius 30 with [ breed = butterflyfishes or breed = pfishes ]
    if any? nearby-fish [
      let target min-one-of nearby-fish[distance myself]
      face target
      fd 3 ] ; move toward fish, sharks are fast
  ] [
    ; random movement
      rt random 50
      lt random 50
      fd 2 ] ; move forward 2 steps because sharks are fast
end

to eat-coral
  if pcolor = orange or pcolor = 116 [
    let nearby-coral-fish patches in-radius 3 with [pcolor = orange or pcolor = 116]
  ; For each nearby coral patch:
    ask nearby-coral-fish [
    ; Fish gains energy from each coral patch
    ; Coral loses growth
    set coral-growth coral-growth - (random (energy-gain-from-coral / 2) + (energy-gain-from-coral / 2))]
    set energy energy + (random (energy-gain-from-coral / 2) + (energy-gain-from-coral / 2))
  ]
end

to clam-eats-larvae
  let clam-prey larvae in-radius 12
    ; Clams eat larvae within radius 12
  if any? clam-prey [
    ask clam-prey [ die ]
    set energy energy + (random (larva-energy / 2) + (larva-energy / 2))
      ]
end

to butterflyfish-eats-larvae
  let bfish-prey larvae in-radius 4 ; Butterflyfish eat larvae within radius 4 because they can move and are fast
  if any? bfish-prey [
    ask bfish-prey [ die ]
    set energy energy + (random-float (larva-energy / 2) + (larva-energy / 2))
    ]
end

to eat-fish
  let prey-pool turtles in-radius 3 with  [ breed = butterflyfishes or breed = pfishes ]
  if any? prey-pool [
    let prey one-of prey-pool
    set energy energy + (random ([energy] of prey) / 2 + ([energy] of prey) / 2 )
    ask prey [ die ]
    ]
end

to reproduce-clam
  let eligible-patches patches with [ (pcolor = orange or pcolor = 116) and count neighbors with [pcolor = orange or pcolor = 116] >= 4 ]
  if any? eligible-patches in-radius 90 [
    if random-float 100 < (clam-reproduction / 100 ) [
      set energy energy / 2
      ask one-of eligible-patches [
        sprout-clams 1 [
          set shape "giant clam"
          set color 107
          set size 18
          set energy random (clam-energy-max / 2) + (clam-energy-max / 2)
        ]
      ]
    ]
  ]
end

to reproduce-bfish
  if count butterflyfishes in-radius 30 >= 2 [
  if random-float 100 < (bfish-reproduction / 100 ) [
      set energy energy / 2
    hatch 1 [
      set breed butterflyfishes
      set shape "butterflyfish"
      set color green
      set size 15
      set energy random (bfish-energy-max / 2) + (bfish-energy-max / 2)
      rt random 360
      fd 1
      ]
    ]
  ]
end

to reproduce-pfish
  if count pfishes in-radius 30 >= 2 [
  if random-float 100 < (pfish-reproduction / 100 ) [
      set energy energy / 2
    hatch 1 [
      set breed pfishes
      set shape "parrot fish"
      set color cyan
      set size 15
      set energy random (pfish-energy-max / 2) + (pfish-energy-max / 2)
      rt random 360
      fd 1
      ]
    ]
  ]
end

to death  ; turtle procedure (i.e. all agents will have this propriety).
  ; when energy dips below zero, die
  if energy < 0 [ die ]
end
;;;;;;;;;;;;;;;;;;;;;;
