Agent goal-list demo

turtles-own [
  id     ;; agent id number or name (usually a copy of "who")
  speed  ;; agent speed in cells per tick
  goal   ;; goal list
]

to setup
  clear-all
  crt 20 [ setxy random-xcor random-ycor
    set speed (0.1 + (random-float (max-agent-speed - 0.1)))
    set size 3
    set id who
    set goal [ "goto" 3 3 "meet" 7 "scatter" "meet" 0 ]
    set label id ]
  reset-ticks
end

to add-goals
  ask turtles [
    set goal (sentence goal (read-from-string new-goal))
    if (verbose) [ show (fput "goal =" goal) ]
  ]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;; NetLogo code for obeying instructions ;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to obey
  if (goal != []) [
    let kind (item 0 goal)
    if-else (kind = "goto") [ if (obey-goto (item 1 goal) (item 2 goal)) [ drop3-goal ] ] [
    if-else (kind = "meet") [ if (obey-meet (item 1 goal)) [ drop2-goal ] ] [
    if-else (kind = "scatter") [ obey-scatter ] [
    obey-unknown kind ] ] ] ]
end

to drop-goal
  set goal (bf goal)
end

to drop2-goal
  set goal (bf (bf goal))
end

to drop3-goal
  set goal (bf (bf (bf goal)))
end

to obey-unknown [ g ]
  show (list "unknown goal" g)
  drop-goal
end

to obey-scatter
  let new-x random-xcor
  let new-y random-ycor
  if (verbose) [ show (list "scattering to" new-x new-y) ]
  set goal (sentence (list "goto" new-x new-y) (bf goal))
end

to-report obey-goto [ x y ]  ;; obey "goto x y" command; report true when achieved
  let d (distancexy x y)
  if-else (d = 0)
    [ if (verbose) [ show (list "already at" x y) ]
      report true ]

    [ facexy x y
      if-else (d <= speed)
        [ setxy x y
          if (verbose) [ show (list "have reached" x y) ]
          report true ]

        [ fd speed
          report false ] ]
end

to-report obey-meet [ ag-id ]  ;; obey "meet agent" command; report true when achieved
  let him (one-of (turtles with [ id = ag-id ]))

  if-else (him = self)
    [ if (verbose) [ show (list "i am" him) ]
      report true ]

    [ face him
      let d (distance him)

      if-else (d <= speed)
        [ move-to him
          if (verbose) [ show (list "have met" him) ]
          report true ]

        [ fd speed
          report false ] ]
end

to go
  if (count (turtles with [ goal != []]) = 0) [ stop ]
  ask turtles [ obey ]
  tick
end
