Buffer

breed [waters water]             ;; water molecules
breed [hydroniums hydronium]     ;; hydronium ions (green)
breed [hydroxides hydroxide]     ;; base molecules (red)
breed [acids acid]               ;; parent acid molecules (yellow)
breed [conj-bases conj-base]     ;; conjugate base molecules of parent acid (orange)

globals [
  pH
]

to setup
  clear-all
  set-default-shape waters "molecule2"
  set-default-shape hydroniums "molecule3"
  set-default-shape hydroxides "molecule1"
  set-default-shape acids "molecule2"
  set-default-shape conj-bases "molecule1"
  create-acids starting-acid  ;; creates variable amount of acid
    [ set color yellow ]
  ask acids [
    ;; initializes amount of dissociated acid
    if random-float 100 > 98
      [ dissociate ] ]
  if see-starting-water?
    [ create-waters 100    ;; creates constant volume of water
        [ set color blue ] ]
  create-conj-bases starting-conj-base  ;; creates variable amount of conjugate base
    [ set color orange ]
  ask turtles                   ;; randomize position and heading of turtles
    [ setxy random-xcor random-ycor ]
  calculate-pH
  reset-ticks
end

;; dissociate an acid molecule into hydronium and conj-base
;; this should only be called by turtles that are acids

to dissociate  ;; turtle procedure
  hatch-hydroniums 1 [ set color green ]
  set breed conj-bases
  set color orange
end

to go
  ask hydroxides [ react-hydroxide ]
  ask hydroniums [ react-hydronium ]
  ;; move turtles randomly around the world
  ask turtles
    [ fd 1
      rt random 10
      lt random 10 ]
  tick
  calculate-pH
end

to react-hydroxide  ;; hydroxide procedure
  let partner one-of hydroniums-here
  ifelse partner != nobody
    [ react partner ]
    [ set partner one-of acids-here
      if partner != nobody
        [ react partner ] ]
end

to react-hydronium  ;; hydronium procedure
  let partner one-of hydroxides-here
  ifelse partner != nobody
    [ react partner ]
    [ set partner one-of conj-bases-here
      if partner != nobody
        [ react partner ] ]
end

to react [ partner ]  ;; turtle procedure
  ;; all hydroxide molecules will instantly react with
  ;; hydronium molecules and form water
  ifelse ([breed] of partner) = hydroniums or ([breed] of partner) = hydroxides
    [ set breed waters
      set color blue
      ask partner
        [ set breed waters
          set color blue ] ]
    [ ;; hydroxide molecules have a high probability of
      ;; reacting with acid molecules
      ifelse ([breed] of partner) = acids
        [ if random-float 100 > 80
          [ set breed waters
            set color blue
            ask partner
              [ set breed conj-bases
                set color orange ] ] ]
        ;; hydronium ions will react with conjugate base to form acid
        [ if ([breed] of partner) = conj-bases
          [ if random-float 100 > 80
            [ set breed waters
              set color blue
              ask partner
                [ set breed acids
                  set color yellow ] ] ] ] ]
end

;; calculates the pH from the amount of the various ions in solution;
;; note that for simplicity the calculations don't take the true molar
;; concentration of water into account; instead we simply divide by
;; a factor of 1000 to bring the numbers into a reasonable range

to calculate-pH
  let volume count turtles
  let concH (count hydroniums / volume)
  let concOH (count hydroxides / volume)
  ifelse (concH = concOH)
    [ set pH 7 ]
    [ ifelse (concH > concOH)
      [ set pH (- log (concH / 1000) 10) ]
      [ let pOH (- log (concOH / 1000) 10)
        set pH 14 - pOH ] ]
end

;; add more base to the system

to add-base
  create-hydroxides added-base
    [ set color red
      fd 1 ]
end

;; add more acid to the system

to add-acid
  create-hydroniums added-acid
    [ set color green
      fd 1 ]
end


; Copyright 2001 Uri Wilensky.
; See Info tab for full copyright and license.
