Tcell

1 collaborator

diana hasan (Author)

WHAT IS IT?

(a general understanding of what the model is trying to show or explain)

HOW IT WORKS

(what rules the agents use to create the overall behavior of the model)

HOW TO USE IT

(how to use the model, including a description of each of the items in the Interface tab)

THINGS TO NOTICE

(suggested things for the user to notice while running the model)

THINGS TO TRY

(suggested things for the user to try to do (move sliders, switches, etc.) with the model)

EXTENDING THE MODEL

(suggested things to add or change in the Code tab to make the model more complicated, detailed, accurate, etc.)

NETLOGO FEATURES

(interesting or unusual features of NetLogo that the model uses, particularly in the Code tab; or where workarounds were needed for missing features)

RELATED MODELS

(models in the NetLogo Models Library and elsewhere which are of related interest)

CREDITS AND REFERENCES

(a reference to the model's URL on the web if it has one, as well as any other necessary credits, citations, and links)

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

breed [tcells tcell]  ; The T cells
breed [DCs DC]  ; The dendritic cells (DCs)

globals [ dt ds tcell-step nDCmeet ]  ; Global variables

links-own [ tDCfree ]  ; Each link tracks how long a T cell is bound to a DC

to setup
  clear-all
  reset-ticks  ; Ensures the tick counter starts at 0

  set-default-shape turtles "circle"  ; All turtles will be circles (spheres)

  set dt 0.5  ; Each time step = 0.5 minutes
  set ds 8    ; 1 patch = 8 µm
  set tcell-step 16 / ds * dt  ; Convert T cell speed to NetLogo units
  set nDCmeet 0  ; Initialize counter for DC-T cell encounters

  create-tcells 100 [
    set color green  ; Make T cells green
    setxyz random-xcor random-ycor random-zcor  ; Place randomly in 3D space
  ]

  create-DCs 2 [
    set size 2  ; Make DCs twice the size of T cells
    set color red  ; Make DCs red
    setxyz random-xcor random-ycor random-zcor  ; Place randomly in 3D space
  ]
end

to go
  move-tcells  ; Move T cells
  identify-DCbound-tcells  ; Identify which T cells should be bound to DCs
  update-link-status  ; Update bound T cells and free them after 3 min
  tick-advance dt  ; Advances time in real minutes
  plotxy ticks nDCmeet  ; Add data to the plot
end

to move-tcells
  ask tcells [
    if not any? my-links [  ; Move only if not bound to a DC
      right random-normal 0 90  ; Pick a random turn angle
      roll-right random-normal 0 90  ; Pick a random roll angle
      forward tcell-step  ; Move forward by computed step size
    ]
  ]
end

to identify-DCbound-tcells
  ask DCs [
    create-links-to tcells with [ color != blue and not any? my-links ] in-radius 2 [  ; Find unlinked T cells in range
      set color red  ; Make the link red to show connection
      set tDCfree 3  ; Bind the T cell for 3 minutes
      ask end2 [
        set color blue  ; Change the T cell's color to blue while bound
        set nDCmeet nDCmeet + 1  ; Increase encounter count
      ]
    ]
  ]
end

to update-link-status
  ask links [
    set tDCfree tDCfree - dt  ; Reduce timer each time step
    if tDCfree <= 0 [  ; If 3 minutes have passed
      ask end2 [ set color green ]  ; Turn the T cell back to green
      die  ; Remove the link
    ]
  ]
end

There is only one version of this model, created 5 months ago by diana hasan.

Attached files

File	Type	Description	Last updated
Tcell.png	preview	Preview for 'Tcell'	5 months ago, by diana hasan	Download
