SIR Model - COVID19

1 collaborator

Paul Smaldino (Author)

WHAT IS IT?

(a general understanding of what the model is trying to show or explain)

HOW IT WORKS

(what rules the agents use to create the overall behavior of the model)

HOW TO USE IT

(how to use the model, including a description of each of the items in the Interface tab)

THINGS TO NOTICE

(suggested things for the user to notice while running the model)

THINGS TO TRY

(suggested things for the user to try to do (move sliders, switches, etc.) with the model)

EXTENDING THE MODEL

(suggested things to add or change in the Code tab to make the model more complicated, detailed, accurate, etc.)

NETLOGO FEATURES

(interesting or unusual features of NetLogo that the model uses, particularly in the Code tab; or where workarounds were needed for missing features)

RELATED MODELS

(models in the NetLogo Models Library and elsewhere which are of related interest)

CREDITS AND REFERENCES

(a reference to the model's URL on the web if it has one, as well as any other necessary credits, citations, and links)

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

;;SIR Model with random movement
;;Agents move around at random.
;;They are either Susceptible, Infected, or Recovered (or, equivalently, removed)
;;
;;Coded in 2020 by Paul Smaldino
;;http://smaldino.com/wp/
;;
;;-----------------------------------------
;;CREATIVE COMMONS LICENSE
;;This code is distributed by Paul Smaldino under a Creative Commons License:
;;Attribution-ShareAlike 4.0 International (CC BY-SA 4.0)
;;https://creativecommons.org/licenses/by-sa/4.0/


globals [max-infected]

turtles-own[
  infected?
  immune?
]

to setup
  clear-all
  setup-turtles
  setup-infected
  set max-infected (count turtles with [infected?])
  reset-ticks
end

to setup-turtles
  create-turtles num-turtles [
    set color white
    set shape "person"
    set size 2
    set infected? false
    set immune? false
    setxy random-pxcor random-pycor
  ]
end

to setup-infected
  ask n-of init-infected turtles [
   set color red
   set infected? true
  ]
end

to go
  ;;stop if everyone or noone is infected
  if (count turtles with [infected?] = 0)
  or (count turtles with [infected?] = num-turtles)
  [stop]

  infect-susceptibles
  recover-infected
  recolor
  move
  calculate-max-infected
  tick
end

to infect-susceptibles ;; S -> I
  ask turtles [
    let infected-neighbors (count other turtles with [color = red] in-radius 1)
    if (random-float 1 <  1 - (((1 - transmissibility) ^ infected-neighbors)) and not immune?)
    [set infected? true]
  ]
end

to recolor
  ask turtles with [infected?]
  [ set color red]
end

to move
  ask turtles [
    right random 360 ;;get a new random heading
    forward speed
  ]
end

to recover-infected ;;I -> R
  ask turtles with [infected?]
  [
    if random-float 1 < recovery-rate
    [
      set infected? false
      ifelse remove-recovered?
      [
        set immune? true
        set color gray
      ]
      [
        set color white
      ]
    ]
  ]
end

to calculate-max-infected
  let x (count turtles with [infected?])
  if x > max-infected
  [set max-infected x]
end

to-report max-infected-prop
  report max-infected / num-turtles
end

to-report prop-uninfected
  report (count turtles with [not infected? and not immune?]) / num-turtles
end
