Spatial Dynamics of Attitude Formation

extensions [rnd];This extension can be dowloaded at https://github.com/NetLogo/Rnd-Extension

globals [
  fizz ; measures the frequency of attitudes that change at each step
  left-freq ;frequency of negative attitudes
  right-freq ; frequency of positive attitudes
  ]

turtles-own [
  old-attitude
  new-attitude
  id-neighbors
  ]

to setup
  clear-all
  ask patches [set pcolor gray]
  set-default-shape turtles "square"
  make-turtle-distribution
  ask turtles [
    set size 1.2
    set old-attitude new-attitude
    set color 5 - ((old-attitude / max-entrench) * 4.9)
  ] ;; in order to do synchronous updating, we need to delay when agents update their attitudes, so we separate attitudes into new and old
  set fizz 0
  measure-frequency-over-time

  reset-ticks
end

to go
  ask turtles [ local-interactions ]
  set fizz (count turtles with [old-attitude != new-attitude]) / count turtles
  ask turtles [
   set old-attitude new-attitude
   set color 5 - ((old-attitude / max-entrench) * 4.9)
  ]
  measure-frequency-over-time
  tick
end

to local-interactions
  let j nobody ; j will be the other agent, which we initially set as nobody
  ifelse influence = "max-inf" or influence = "min-inf" [
    if influence = "max-inf" [
      set j max-one-of turtles-on neighbors [abs old-attitude] ]
    if influence = "min-inf" [
      set j min-one-of turtles-on neighbors [abs old-attitude] ]
  ]
  [
    let localsum 0 ; This will be sum of the neighbour attitudes, weighted by the influence function.
    let pairlist [] ; this is going to be the list of pairs with a turtle first and a probability second
    ask turtles-on neighbors [
      set localsum localsum + abs influence-function [old-attitude] of self ]
    ask turtles-on neighbors [
      let prob 0
      if localsum != 0 [set prob (abs influence-function [old-attitude] of self) / localsum]
      let pair []
      set pair lput self pair
      set pair lput prob pair
      set pairlist lput pair pairlist
    ]
    set j first rnd:weighted-one-of pairlist [last ?]
  ]
  if is-turtle? j [ ;it is possible that no agent ends up getting picked in the line above, so this checks that someone has
    ifelse random-float 1 < opinion-amplification [
      if [old-attitude] of j > 0 [
        if abs old-attitude < max-entrench [
          ifelse old-attitude = -1 [set new-attitude 1] [ set new-attitude old-attitude + 1 ]]
      ]
      if [old-attitude] of j < 0 [
        if abs old-attitude < max-entrench [
          ifelse old-attitude = 1 [set new-attitude -1] [set new-attitude old-attitude - 1 ]]
      ]]
    [
      if [old-attitude] of j > old-attitude [
        ifelse old-attitude = -1 [set new-attitude 1] [ set new-attitude old-attitude + 1]]
      if [old-attitude] of j < old-attitude [
        ifelse old-attitude = 1 [ set new-attitude -1][set new-attitude old-attitude - 1 ]]
    ]
  ]
end

to-report influence-function [item1]
  if influence = "linear" [
    ifelse item1 = 0 [report 1] [report item1] ]  ; this is the linear update function
  if influence = "square" [
    ifelse item1 = 0 [report 1] [report (item1 ^ 2)]] ; this weighs extreme attitudes more than moderate ones
  if influence = "uniform" [
    if item1 < 0 [report -1]
    if item1 > 0 [report 1] ]
  if influence = "co-linear" [
    ifelse item1 = 0 [report 1] [report (max-entrench + 1 - abs item1) ] ]
  if influence = "co-square" [
    ifelse item1 = 0 [report 1] [report (max-entrench + 1 - abs item1) ^ 2 ] ]
end

to make-turtle-distribution
ifelse rnd-initial [
    ask patches [;; every patch will either have a positive or negative attitude placed on them. The probability of one over the other is set by polluter-to-nonpolluter-ratio
    ifelse random-float 1 < positive-to-negative-ratio [
      sprout 1 [
        set new-attitude (random init-attitude) + 1
      ]
    ]
    [
      sprout 1 [
        set new-attitude 0 - (random init-attitude) - 1
      ]
    ]
  ]
][;;otherwise, the positive attitudes are arranged to form a circle, with a radius set by radius-size
ask patches [
    ifelse (abs pxcor) ^ 2 + (abs pycor) ^ 2 <= radius-size ^ 2 [
      sprout 1 [
        set new-attitude max-entrench
      ]
    ]
    [
      sprout 1 [
        set new-attitude (0 - max-entrench)
      ]
    ]
  ]
]
end

;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;; STATISTICS
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;

to measure-frequency-over-time
  set left-freq count turtles with [old-attitude <= -1] / count turtles
  set right-freq count turtles with [old-attitude >= 1] / count turtles
end

;; Copyright Bert Baumgaertner
;; See info tab for credits
