Monte Carlo -self localization algorithm

1 collaborator

Joan Puig (Author)

WHAT IS IT?

(a general understanding of what the model is trying to show or explain)

HOW IT WORKS

(what rules the agents use to create the overall behavior of the model)

HOW TO USE IT

(how to use the model, including a description of each of the items in the Interface tab)

THINGS TO NOTICE

(suggested things for the user to notice while running the model)

THINGS TO TRY

(suggested things for the user to try to do (move sliders, switches, etc.) with the model)

EXTENDING THE MODEL

(suggested things to add or change in the Code tab to make the model more complicated, detailed, accurate, etc.)

NETLOGO FEATURES

(interesting or unusual features of NetLogo that the model uses, particularly in the Code tab; or where workarounds were needed for missing features)

RELATED MODELS

(models in the NetLogo Models Library and elsewhere which are of related interest)

CREDITS AND REFERENCES

(a reference to the model's URL on the web if it has one, as well as any other necessary credits, citations, and links)

Comments and Questions

Please start the discussion about this model! (You'll first need to log in.)

Click to Run Model

;Montecarlo-selflocalization algorithm

globals [TheColor myxcor myycor totalP sensor_color i1 i2 lastx lasty diffX diffY]

patches-own [p mycolor]
turtles-own []

to setup

clear-all

ask patches[set pcolor one-of[green yellow brown blue] set p 1 / count(patches) set totalP sum[p]of patches set mycolor pcolor]

ask one-of patches

[
  sprout 1[

    set shape "circle"
    set color red
    set size 0.8

  ]

]
end

to moveup

  ask turtles
  [
    set ycor ycor + 1
  ]
  ask patches
  [
    set p (move-right * [p] of patch-at 0 (- 1)) + (1 - move-right) * p
  ]
  sense
end

to movedown

  ask turtles
  [
    set ycor ycor - 1
  ]
  ask patches
  [
    set p (move-right * [p] of patch-at 0 1) + (1 - move-right) * p
  ]
  sense
end

to moveright

  ask turtles
  [
    set xcor xcor + 1
  ]
  ask patches
  [
    set p (move-right * [p] of patch-at (- 1) 0) + (1 - move-right) * p
  ]
  sense
end

to moveleft

  ask turtles
  [
    set xcor xcor - 1
  ]
  ask patches
  [
    set p (move-right * [p] of patch-at 1 0) + (1 - move-right) * p
  ]
  sense
end

to sense

  ;ask turtles with [color = white][set sensor_color [mycolor] of patch-ahead 0]
  ask turtles [ask patch-here [set sensor_color mycolor]]

  ask patches
  [
    ifelse mycolor = sensor_color
    [
      set p p * sensor-right
    ][
      set p p * (1 -  sensor-right)
    ]
  ]
  set totalP sum[p]of patches

  ask patches
  [
    set p p / totalP
  ]

  ask patches
  [
    set pcolor scale-color green p 0 light
  ]
end

to move


ask turtles
[
  set i1 one-of [0 1 -1]
  set i2 one-of [0 1 -1]

  set xcor xcor + i1
  set ycor ycor + i2
]

ask patches [set p (move-right * [p] of patch-at (- i1) (- i2) + (1 -  move-right) * p)]


  ask patches
  [
    set pcolor scale-color green p 0 light
  ]
end

to go

  move

  sense
end

to go1
  if mouse-down?
  [
    sense1
    move1

  ]
end

to s_color

  ask patches [set pcolor mycolor]
end

to move1



ask patch mouse-xcor mouse-ycor [set diffX (lastx - mouse-xcor) set diffY (lasty - mouse-ycor)]

ask patches [set p (move-right * [p] of patch-at (diffX) (diffY) + (1 -  move-right) * p)]

ask patch mouse-xcor mouse-ycor [set lastx mouse-xcor set lasty mouse-ycor]
end

to sense1

  ;ask turtles with [color = white][set sensor_color [mycolor] of patch-ahead 0]
  ask patch mouse-xcor mouse-ycor [set sensor_color mycolor]

  ask patches
  [
    ifelse mycolor = sensor_color
    [
      set p p * sensor-right
    ][
      set p p * (1 -  sensor-right)
    ]
  ]
  set totalP sum[p]of patches

  ask patches
  [
    set p p / totalP
  ]

  ask patches
  [
    set pcolor scale-color green p 0 light
  ]
end

There is only one version of this model, created over 10 years ago by Joan Puig.
